Midea MGB Series

MCAC-ATSM-2011-12 Air-cooled modular chiller unit 50Hz
11
Model MGB-D25W/RN1 MGB-D30W/RN1
Cooling Capacity
kW 28 30
Btu/h 95,500 102,300
Heating Capacity kW 29.5 32
Power supply V/Ph/Hz 380-415/3/50
Power supply
Manual switch A 50
Fuse A 36
Compressor
Type Constant Speed Scroll + Digital Scroll
Quantity Pieces 1+1
Model
ZP67KCE-TFD-522+
ZPD67KCE-TFD-532
Brand Copeland
Capacity W 16200+16200
Input W 5200+5260
Rate current(RLA) A 9.1+9.3
Locked rotor Amp(LRA) A 74+74
Power input
Cooling kW 9.3 10.0
Cooling rated current A 14.6 16.3
Heating kW 9.2 9.8
Heating rated current A 14.3 16
Max. Input consumption A 12.5
Max. Current A 21.5
Refrigerant
Type R410a
Weight kg 3.5×2
Refrigerant control EXV+ capillary throttle
Condenser
(Air side)
Air side heat-exchanger type Copper-fin-coil
Quantity of fan motor Pieces 1
Air flow volume ×10
3
m
3
/h 12
Fan motor input kW 0.3
Evaporator
(Water side)
Water side heat-exchanger type Double-pipe heat exchanger
Water resistance loss kPa 60
Water inlet/outlet pipeline inside
normal diameter
mm DN40
inch 1-1/2”
Water flow volume m
3
/h 4.4 5.2
Max. Pressure MPa 1
Water pipe connection type Flexible joint
Dimension
Net(W×H×D)
mm
1514×1865×841
inch
59.6×73.4×33.1
Packing(W×H×D)
mm
1590×2065×995
inch
62.6×81.3×39.2
Weight
Net weight kg 380
Operation weight kg 400
Connection wire
Power wire mm
2
×No. 10×4+10×1
Signal wire mm
2
×No. 0.75×3-core
Control type Wired controller
