Midea MGB Series

MCAC-ATSM-2011-12 Air-cooled modular chiller unit 50Hz
15
Model MGB-F55W/RN1 MGB-F60W/RN1 MGB-F65W/RN1
Cooling Capacity
kW 55 60 65
Btu/h 187,660 204,700 221,780
Heating Capacity kW 59 64 69
Power supply V/Ph/Hz 380-400/3/50
Power
supply
Manual switch A 125
Fuse A 100
Compressor
Type Fixed speed Scroll
Quantity Pieces 2
Model SH140A4ALC
Brand Danfoss
Capacity W 34700×2
Input W 10860×2
Rate current(RLA) A 21.4×2
Locked rotor Amp(LRA) A 147×2
Power input
Cooling kW 17.5 19.3 20.4
Cooling rated current A 30.5 33.6 36.5
Heating kW 18.3 19.8 21.5
Heating rated current A 31.5 34.3 37.2
Max. Input consumption A 28.2
Max. Current A 47.6
Refrigerant
Type R410a
Weight kg 7×2
Refrigerant control EXV+ capillary throttle
Condenser
(Air side)
Air side heat-exchanger type Copper-fin-coil
Quantity of fan motor Pieces 2
Air flow volume ×10
3
m
3
/h 24
Fan motor input kW 0.65
Evaporator
(Water side)
Water side heat-exchanger type Shell and tube
Water resistance loss kPa 15
Water inlet/outlet pipeline
inside normal diameter
mm DN100
inch 4”
Water flow volume m
3
/h 9.4 10.3 11.2
Max. Pressure MPa 1
Water pipe connection type Flexible joint
Dimension
Net(W×H×D)
mm
2000×1880×900
inch
78.7×74×35.4
Packing(W×H×D)
mm
2090×2055×985
inch
82.3×80.9×38.8
Weight
Net weight kg 580
Operation weight kg 650
