MCAC-ATSM-2011-12 Air-cooled modular chiller unit 50Hz
17
Model
MGB-D65W/RN1
Cooling Capacity
kW 65 130 185
Btu/h 221,780 443,560 631,220
Heating Capacity kW 69 138 200
Power supply V/Ph/Hz 380-415/3/50 380-400/3/50 380-400/3/50
Power
supply
Manual switch A 150 250 400
Fuse A 100 200 300
Compressor
Type Scroll (fixed speed+digital scroll) Fixed speed Scroll Fixed speed Scroll
Quantity Pieces 3 4 6
Model
ZP144KCE-TFD-522 /
ZPD72KCE-TFD-433 /
ZP67KCE-TFD-420
SH140A4ALC SH140A4ALC
Brand Copeland Danfoss Danfoss
Capacity kW 36 17 16.3 34.7×4 34.7×6
Input kW 10.8 5.75 5.2 10860×4 10860×6
Rate current(RLA) A 18.7 9.8 9.1 21.4×4 21.4×6
Locked rotor Amp(LRA) A 144 82.4 74 147×4 147×6
Power input
Cooling kW
20.4
40.8 63
Cooling rated current A
36.5
73 110
Heating kW
21.5
43.0 61
Heating rated current A
37.2
74.4 107
Max. Input consumption A
28.2 55.5 78.3
Max. Current A
47.6 93.8 133.4
Refrigerant
Type R410a R410a R410a
Weight kg 7×2 7×4 7×6
Refrigerant control EXV+ capillary throttle
EXV+ capillary
throttle
EXV+ capillary
throttle
Condenser
(Air side)
Air side heat-exchanger type Copper-fin-coil Copper-fin-coil Copper-fin-coil
Quantity of fan motor Pieces 2 4 6
Air flow volume ×10
3
m
3
/h 24 48 72
Fan motor input kW 0.55×2 1.3 1.3
Evaporator
(Water side)
Water side heat-exchanger type Shell and tube Shell and tube Shell and tube
Water resistance loss kPa 15 25 30
Water inlet/outlet
pipeline inside normal
diameter
mm DN100 DN65 DN80
inch 4’’ 2-1/2” 3”
Water flow volume m
3
/h 11.2 22.4 31.8
Max. Pressure MPa 1 1 1
Water pipe connection type Flexible joint Flexible joint Flexible joint
Dimension
Net(W×H×D)
mm 2000×1880×900
2000×2090×1685 2850×2110×2000
inch 78.7×74×35.4
78.7×82.3×66.3 112.2×83.1×78.7
Packing(W×H×D)
mm 2090×2020×985
2090×2240×1755 2980×2260×2135
inch 82.3×80.9×38.8
82.3×88.2×69 117.3×89×84.1
MBG-F130W/R(S)N1
MGB-F185W/R(S)N1
