Midea MGB Series

MCAC-ATSM-2011-12 Air-cooled modular chiller unit 50Hz
19
Model MGBT-F250W/RN1
Cooling Capacity
kW
250
Btu/h
830,000
Heating Capacity kW 270
Power supply V/Ph/Hz 380-400/3/50
Power supply
Manual switch A 450
Fuse A 350
Compressor
Type Scroll (fixed speed)
Quantity Copeland 8
Model SH120A4ALC
Brand
Copeland
Capacity W
111231
Input W
10275
Rate current(RLA) A
20.88
Locked rotor Amp(LRA) A
177
Power input
Cooling kW
78.3
Cooling rated current A
141.9
Heating kW
80
Heating rated current A
146
Max. Input consumption A
104.9
Max. Current A
194.6
Refrigerant
Type R410A
Weight kg 15×4
Refrigerant control EXV+ capillary throttle
Condenser
(Air side)
Air side heat-exchanger type Fin-coil
Quantity of fan motor Pieces 8
Air flow volume ×10
3
m
3
/h 96
Fan motor input kW 5.6
Evaporator
(Water side)
Water side heat-exchanger type Shell-tube
Water resistance loss kPa 40
Water inlet/outlet pipeline inside
normal diameter
mm DN100
inch 4”
Water flow volume m
3
/h 43
Max. Pressure MPa 1
Water pipe connection type Flexible joint
Dimension
Net(W×H×D)
mm
3800×2130×2000
inch
149.6×83.86×78.74
Packing(W×H×D)
mm
3900×2200×2100
inch
153.54×86.61×82.68
Weight
Net weight kg 2450
Operation weight kg 2600
Connection wire
Power wire mm
2
×No. 185×4+70×1
Signal wire mm
2
×No. 0.75×3-core with shielding
Control type Wired controller
