Midea MGB Series

MCAC-ATSM-2011-12 Air-cooled modular chiller unit 50Hz
83
No. Part Name
Qty BOM code No. Part Name Qty BOM code
17.5
Pipe joint
3 201601200004 42
Cover
1 201295300096
18
Base ass'y
1 201290190056 43
Left-side board ass'y
1 201290190232
19
Electrical box ass'y
1 203390190029 44
Rear cover
1 201290190223
19.1
Electronic installation board
1 201290190227 45
Front cover
1 201290100235
19.2
Dual Relay
1 202300830544 46
Top cover
1 201290140111
19.3
Compressor capacitor
1 202401000410 47
Maintenance window in the
bulkhead cover
1 201290501495
19.4
Low temp. cooling module
ass'y
1 201390190028 48
Welding part of middle
separation board
1 201290190205
19.5
Relay
1 202300800003 49
Outlet pipe fixed base
1 201290190287
19.6
Contactor
2 202300850043 50
Net
2 201290190118
19.7
Contactor
1 202300800110 51
Clapboard supporting board
3 201295010094
19.8
Three-phase power
protection devices
1 202301600518 52
About clapboard
1 201295500014
19.9
Wire joint
4 202301450122 53
Top cover
1 201195300051
19.10
Wire joint
1 202301450110 54
D machine back to the tube
components
1 201690191306
19.11
Wire joint
1 202301450132 54.1
Pipe joint
1 201601200004
19.12
Wire joint,11p
1 202301400365 55
D machines take over the
assembly solenoid valve
1 201690101464
19.13
Outdor main board ass'y
1 201390190026 55.1
Pressure-relief-valve
1 201600600501
19.14
Transformer
1 202300900109 55.2
Strainer
1 201600900040
19.15
Outdoor current detection
board ass'y
1 201390190020 56
B components of the left seal
plate condenser
1 201290190123
20
The door welding part of
electrical box
1 201290190224 57
Axial flow fan
1 201200300013
21
The welding part of small
baseplate
1 201290190233 58
Motor
1 202400401168
22
Base
1 201290190103 59
Motor bracket bonding parts
2 201290590191
