Midea MGB Series

MCAC-ATSM-2011-12 Air-cooled modular chiller unit 50Hz
89
No. Part Name
Qty BOM code No. Part Name Qty BOM code
3.1
Condenser ass'y of A
1 201590100030 28.1
Pressure controller
1 202301820073
3.2 Fluted pipe ass'y A 1 201690101439 29
A machine back to the tube
ass'y
1 201690191377
3.3
The condenser splitter
assemblies A
1 201690101393 29.1 Pressure controller 1 202301820073
4 Condenser ass'y B 1 201590100024 30
A four-way valve assembly
machine
1 201690191339
4.1 Condenser ass'y of B 1 201590100031 30.1 4-way valve 1 201600600110
4.2 Fluted pipe ass'y B 1 201690101440 30.2 Pressure controller 1 202301820014
4.3
The condenser splitter
assemblies B
1 201690101392 30.3 Pressure controller 1 202301800840
5 Mid horizontal support 2 201290100219 30.4 Pipe joint 2 201601200004
6 Fixed board 2 201290100233 31 Four-way valve ass'y of A 1 201690191390
7 Mid upright support 2 201290100211 31.1 4-way valve 1 201600600110
8 Pipe fixing clamp 2 201252600035 31.2 Pressure controller 1 202301820014
9 Evaporator input pipe ass'y 1 201690191273 31.3 Pressure controller 1 202301800840
9.1 Electronic expansion valve 1 201601300018 31.4 Pipe joint 2 201601200004
9.2 Strainer 2 201600910001 32 Drainage pan ass'y 1 201290100195
10
Evaporator input pipe ass'y
of A
1 201690191395 33 Middle partition plate 2 201290100248
10.1 Electronic expansion valve 1 201601300018 34 Net 2 201290100240
10.2 Strainer 2 201600910001 35 Net 4 201290100237
11 Cover 1 201290100241 36 Top upright support 2 201290100191
12 Cover 1 201290100246 37 Condenser seal connector 1 201290108626
13 Triangle reinforcement ass'y 8 201290100218 38 Top cover 2 201195300051
14 Reinforcement board 4 201290100247 39 Axial flow fan 2 201200300013
15 Base 1 201290190198 40 Discharge pipe ass'y of A 1 201690191381
16
Supporting ass'y of
compressor
2 201290190199 41 Motor 2 202400401168
17 Cover 1 201290100243 42 Mid horizontal support 2 201290100223
18 Wiring terminal fixing board 1 201290100193 43 Motor bracket ass'y 4 201290100005
19 Cover 1 201290100244 44 Condenser seal connector 1 201290108625
20 Cover 1 201290100245 45 Unload valve ass'y 1 201690191392
21 Outdoor electric box ass'y 1 203390190028 45.1 Pressure-relief-valve 1 201600600501
21.1
Welding together pieces of
electronic control box
1 201290190144 46
Fixed plate with the
condenser B
1 201290108629
21.2 Electronic installing board 1 201290190196 47 EEV solenoid coil 2 201601300516
21.3 Outdoor main board ass'y 1 201390190017 48 Discharge temp sensor 3 202301610027
21.4
Outdoor current detection
board ass'y
1 201390190024 49 Room temp sensor ass'y T41 1 202301300403
21.5 Relay 3 202300800003 50 Coil temp. sensor ass'y 2 202301300401
21.6 Contactor 2 202300850043 51 Temp.sensor ass'y 1 202301300083
21.7 AC contactor 1 202300850050 52 Coil temp sensor ass'y 3 202301300081
21.8 Transformer 1 202300900109 53 Compressor electric heater 1 202403100031
21.9 Wire joint,11p 1 202301400365 54 Compressor electric heater 2 202403100254
21.10 Wire joint,4p 1 202301450003 55 4-Ways valve solenoid 2 201600600103
21.11 Wire joint 1 202301450110 56 R410A 14 200500100003
21.12 Wire joint 3 202301450122 57 Compressor 1 201401400740
21.13
Three-phase power
protection devices
1 202301600518 58 Compressor 1 201401420040
21.14 Compressor capacitor 2 202401000410 59 Compressor 1 201401420030
22 Wiring trough 0.5 201119900945 60
Gas balance pipe of
compreesor
1 201690191384
23 Vapor-liquid separator 2 201601100111 61 Oil balance pipe ass'y 1 201690191385
24 Shell and tube evaporator 1 201790190017 62
Total water temperature
mouth components
1 201690101220
25 Cover 1 201290100242 63
Accessory- wired
controller(English)
1 203355100572
