MGC-F10W/SN1
Ta.
U.R.87%
Tw 35 40 45 50
Pt 8.3 8.3 8.3 -
Pa 3.0 3.2 3.5 -
Pat 3.5 3.7 4.0 -
Qc 1.4 1.4 1.4 -
-5
△Pc
19.6 18.9 18.0 -
Pt 9.4 9.4 9.4 9.2
Pa 3.1 3.3 3.6 3.8
Pat 3.6 3.8 4.1 4.3
Qc 1.7 1.6 1.6 1.6
0
△Pc
27.5 25.6 24.8 23.2
Pt 11.4 11.3
11.2
11.1
Pa 3.3 3.6 3.8 4.1
Pat 3.8 4.1
4.3
4.6
Qc 2.0 2.0
2.0
1.9
7
△Pc
37.2 35.8
34.5
33.1
Pt 12.3 12.2 12.1 12.0
Pa 3.4 3.7 3.9 4.2
Pat 3.9 4.2 4.4 4.7
Qc 2.1 2.1 2.1 2.1
10
△Pc
40.5 40.0 39.2 38.8
Pt 13.8 13.7 13.6 13.5
Pa 3.5 3.8 4.0 4.3
Pat 4.0 4.3 4.5 4.8
Qc 2.4 2.4 2.3 2.3
15
△Pc
45.8 45.1 43.6 42.9
Note:
Ta: outside air temperature (°C)
Tw : evaporator water outlet temperature (°C)
Pt: heating capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qc: condenser water flow (m
3
/h)
ΔPc: evaporator pressure drop (kPa)
- : Exceed operating limits
