MCAC-TSM-2008-02 Outdoor units
Outdoor units 47
No. Part Name Quantity No. Part Name Quantity
1 Rear support board II 1 24.1 Water charge valve 1
2 Condenser 1 24.2 Safety valve 1
3 Fluted pipe ass'y 1 24.3 Water-inlet pipe adapter 1
4 Input pipe ass'y 1 25 Connecting pipe ass'y of liquid accumulator 1
5 Expansion vessel 1 25.1 Capillary 1
6 Accumulator cylinder 1 25.2 Liquid accumulator can 1
7 Partition board ass'y 1 26 Heat-exchanger plate ass'y 1
8 Expansion tank clamp 1 27 Fixing board 1
9 Rear net clip 1 28 Left fixing board 1
10 Drain Pump 1 29 Holder 1
11 Expansion tank joint pipe ass'y 1 30 4-way valve ass'y 1
11.1 Discharge valve 1 30.1 4-way valve 1
12 E-part box ass'y 1 30.2 4-Ways valve solenoid 1
12.1 Motor capacitor 2 31 Discharge pipe ass'y 1
12.2 E-part box 1 31.1 Pressure controller 1
12.3 Filter board ass'y 1 32 Suction pipe ass'y 1
12.4 Transformer 1 32.1 Pressure controller 1
12.5 AC contactor 1 33 Compressor 1
12.6 ELIWELL Controller 1 34 Fixing board 1
12.7 Power supply control board ass'y 1 35 Display cover ass'y 1
12.8 Terminal 23 36 Front panel 1
12.9 Surge suppresser 1 37 Base weldment 1
13 Top cover ass'y 1 38 Grille 2
14 Pressure difference valve 1 39 Axial flow fan 2
15 Front clapboard ass'y 1 40 Motor bracket ass'y 1
16 Rear clapboard ass'y 1 41 Motor 2
17 Urgency switch 1 42 Supporting board 1
18 Hydraulic meter 2 43 Rear net 1
19 Temp. sensor ass'y 1 44 Discharge temp. sensor 1
20 Drain pipe adapter 1 45 Temp. sensor ass'y 3
21 Handle 1 46 Compressor electric heater 1
22 Connecting pipe ass'y 1 47 Pressure difference valve electric heater 1
23 Water pipe ass'y 1 48 Connecting board for condenser 1
24 Water-inlet pipe ass'y 1
