MCAC-TSM-2008-02 Outdoor units
Outdoor units 51
No. Part name Quantity No. Part name Quantity
1 Condenser assembly 1 18 Handle 2
2 Middle partition plate subassembly 1 19 Adapter, drain pipe 1
3 Expansion vessel 1 20 Display cover subassembly 1
4 Accumulator cylinder 1 21 Bearing 1
5 Water Pump 1 22 Left fixing board 1
6 Rear net clip 1 23 Plate Heat-exchanger assy assembly 1
7 Expansion tank joint pipe assembly 1 23.1
Differential pressure valve tie-in
subassembly
1
7.1 Discharge valve 1 23.2 Rubber gasket 1
7.2 Discharge valve joint 1 23.3 Electric heater 1
7.3 Joint nut 1 23.4 Plate Heat-exchanger 1
8 Electronic control box subassembly 1 24 4-way valve subassembly 1
8.1 E-part box 1 24.1 4-way valve 1
8.2 Motor capacitor 2 24.2 Pipe joint 2
8.3 Surge suppresser 1 24.3 Control wire for 4-Ways valve 1
8.4 Transformer 1 25 Right fixing board 1
8.5 Controller power supply wire 1 26 Discharge pipe subassembly 1
8.6 Power supply control board subassembly 1 26.1 Pressure controller 1
8.7 Controller signal wire 1 27 Water-inlet pipe assembly I 1
8.8 Controller subassembly 1 27.1 Make-up water valve 1
8.9 Power supply blue wire 1 27.2 Check valve tie-in 1
8.10 Gas protection signal wire 1 27.3 Safety valve 1
8.11 Liquid protection signal wire 1 27.4 Water-inlet pipe tie-in 1
8.12 Protection signal wire joint 1 27.5 Hex nut 1
8.13 Washer for wire joint 1 28 Suction pipe subassembly 1
8.14 Remote protection signal wire 1 28.1 Pressure controller 1
8.15 Signal wire joint 1 29 Compressor 1
8.16
Power supply sieve wave board
subassembly
1 30 Front panel 1
9
Differential pressure valve below joint pipe
assembly
1 31 Chassis Ass'y 1
9.1 Copper nut 2 32 Net for air-out frame 2
10 Top cover subassembly 1 33 Axial flow fan blade 2
11 Up conjunction pipe subassembly 1 34 Motor mounting bracket subassembly 1
11.1 Rubber gasket 2 35 Outdoor fan Motor 2
11.2 Transition pipe union 2 36 Right cover subassembly 1
11.3 Hex nut 3 37 Fixture, Segregator 1
11.4 Hex nut 1 38 Capillary pipe subassembly 1
11.5 Copper nut 1 39 liquid accumulator can assembly 1
12 Front right clapboard subassembly 1 39.1 liquid accumulator can 1
13 Rear right clapboard subassembly 1 40 Rear net 2
14 Urgency Switch 1 41 Left cover 1
15 Hydraulic surface 1 42 Temperature sensor subassembly 4
16 Expansion can clamp 1 43 Discharge temp sensor 1
17 Differential pressure valve 1
