Midea MHA-192HWN1 User Manual

R410A 380~415V 3Ph 50Hz TempMaker Series Split AC MCAC-UTSM-2014-03
55
Model
MOV-120HN1-R
MOV-150HN1-R
Power supply
\
380-415V~, 3Ph, 50Hz
380-415V~, 3Ph, 50Hz
Ambient temp in cooling
°C
17～46
17～46
Ambient temp in heating
°C
-7~24
-7~24
Rated input (Outdoor unit)
W
17,300
26,900
Rated current (Outdoor unit)
A
28.6
47.9
Noise level
dB(A)
69
70
Compressor
Type ×Qty.
\
Scroll ×1
Scroll ×3
Brand
\
Danfoss
Hitachi
Model
\
SH140A4ALC
E605DH-59D2YG
Capacity
W
34,700
15,390
Input
W
10,862
5,130
Rated current
A
21.4
8.8
Locked rotor Amp
A
147
62
Refrigerant oil
ml
3,300 (POE-160SZ)
500 (FVC68D)
Refrigerant type/charge
\
R410A/7,500g
R410A/10,000g
Fan
Type ×Qty.
\
Axial fan ×2
Axial fan ×2
Motor model
\
YDK400-4C
YDK380-4D
Motor input (4/3 fan blades)
\
Hi: 621/587; Lo: 388
Hi: 615/580; Lo: 425/420
Capacitor
\
25μF/450V
20μF/450V
Motor speed (4/3 fan blades)
rpm
Hi: 1,180/1,230; Lo: 790/870
Hi: 1000/1090; Lo: 780/870
Coil
Type
\
Copper tube and aluminum fin
Copper tube and aluminum fin
Tube size
mm
Φ7
Φ7.94
No. of rows
\
3
2
Fin space
mm
1.3
1.6
Tube pitch(a)×row pitch(b)
mm
21×13.37
22×19.05
Coil (W×H)
mm
(1,380×882)+(1,380×882)
2,286×1,232
Number of circuits
\
20+20
28
Refrigerant
pipe
Liquid side/ Gas side
mm
Ф12.7/Ф28.6
Ф16/Ф32
Max. pipe length
m
50
50
Max. difference in level
\
25m(O.D. up) /30m(O.D. down)
Connection
wire
Power wire
\
5×10.0mm
2
5×16.0mm
2
Signal wire
\
4×1.0mm
2
4×1.0mm
2
Dimension (W×H×D)
mm
1,255×908×700
1,250×1,615×765
Packing (W×H×D)
mm
1,320×1,060×730
1,305×1,790×820
Net/ Gross weight
kg
201/217
288/308
Notes:
1. Rated input = Max. input, Rated current = Max. current.
2. Nominal cooling capacities are based on the following conditions: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 35°CDB; Nominal heating capacities are based on the following conditions: Indoor temp: 20°CDB;
Outdoor temp: 7°CDB, 6°CWB.
