M thermal Mono
34 200204
Midea M thermal Mono Service Manual
MHC-V12W/W/D2RN8-B / MHC-V14W/W/D2RN8-B / MHC-V16W/W/D2RN8-B
Figure 4-1.4: Electric control box front view
Main PCB for refrigerant system
Main PCB for hydronic system
Inverter module Outdoor unit power supply
terminals
Communication terminal blocks
