How to remove the compressor.
1) Perform work of item 1 step
5~6 and item 2..
2) Extract refrigerant gas.
3) Remove the sound
insulation material and
crankcase heating cable.
4) Remove terminal cover of
compressor, and disconnect
wires of crankcase electric
heater and compressor from
the terminal.
5) Remove the discharge pipe
and suction pipe with a
burner.
6) Remove the hex nuts and
washers fixing the
compressor to bottom plate.
7) Lift the compressor.
To Next Page
