Midea MKA-1200R - Capacity Tables

MCAC-KTSM-2012-02 4-way cassette FCU
Capacity Tables 13
10. Capacity Tables
Cooling Capacity:
Remark: EWT: Enter Water Temp. (℃); Δt: Temperature Difference (℃)
DB: Dry Bulb Temp. (℃); WB: Wet Bulb Temp. (℃);
TC: Total Cooling Capacity (kW); SC: Sensible Cooling Capacity (kW);
WF: Water Flow (m
3
/h); WPD: Water Pressure Drop (kPa)
MKA-600R(A)
EWT ∆t
Air inlet condition
DB:26.7 WB:19.4 DB:27 WB:18 DB:27 WB:19 DB:27 WB:20 DB:29 WB:21
TC SC WF WPD TC SC WF WPD TC SC WF WPD TC SC WF WPD TC SC WF WPD
5
3
7.26 4.38 2.08 107.3 6.66 4.81 1.91 90.3 7.11 4.56 2.04 103.0 7.53 4.37 2.16 115.3 7.95 4.17 2.28 128.5
4
6.98 4.24 1.50 55.8 6.42 4.66 1.38 47.1 6.87 4.43 1.48 54.0 7.27 4.24 1.56 60.5 7.63 4.03 1.64 66.7
5
6.68 4.10 1.15 32.7 6.11 4.56 1.05 27.4 6.55 4.29 1.13 31.4 6.98 4.09 1.20 35.7 7.34 6.34 1.26 39.4
6
6.38 3.98 0.91 20.7 5.82 4.40 0.83 17.2 6.26 4.15 0.90 19.9 6.70 3.93 0.96 22.8 7.02 3.73 1.01 25.0
7
6.07 3.79 0.75 13.8 5.49 4.29 0.68 11.3 5.93 4.01 0.73 13.1 6.37 3.79 0.78 15.2 6.72 3.59 0.83 16.9
6
3
6.85 4.20 1.96 95.5 6.24 4.63 1.79 79.3 6.70 4.38 1.92 91.2 7.13 4.18 2.04 103.5 7.54 3.98 2.16 115.8
4
6.58 4.05 1.41 49.6 5.96 4.48 1.28 40.7 6.42 4.24 1.38 47.2 6.85 4.05 1.47 53.7 7.24 3.85 1.56 60.0
5
6.26 3.91 1.08 28.7 5.69 4.36 0.98 23.7 6.14 4.11 1.06 27.6 6.54 3.87 1.12 31.3 6.95 3.70 1.20 35.4
6
5.96 3.79 0.85 18.1 5.40 4.21 0.77 14.8 5.82 3.96 0.83 17.3 6.26 3.73 0.90 19.9 6.60 3.54 0.95 22.2
7
5.65 3.62 0.69 11.9 5.06 4.10 0.62 9.6 5.51 3.85 0.68 11.4 5.91 3.60 0.73 13.0 6.31 3.39 0.78 14.9
7
3
6.40 4.00 1.83 83.3 5.81 4.45 1.66 68.6 6.26 4.20 1.79 79.7 6.72 3.99 1.93 91.9 7.10 3.78 2.03 102.5
4
6.14 3.86 1.32 43.1 5.50 4.35 1.18 34.7 5.97 4.06 1.28 40.8 6.42 3.86 1.38 47.1 6.82 3.66 1.47 53.2
5
5.82 3.72 1.00 24.8 5.22 4.21 0.90 20.0
5.70 3.92 0.98 23.8 6.11 3.68 1.05 27.4 6.49 3.51 1.12 30.9
6
5.52 3.61 0.79 15.5 4.92 4.08 0.71 12.3 5.42 3.78 0.78 15.0 5.83 3.55 0.84 17.3 6.19 3.36 0.89 19.5
7
5.22 3.45 0.64 10.2 4.59 3.93 0.56 7.9 5.05 3.67 0.62 9.5 5.49 3.43 0.67 11.3 5.86 3.22 0.72 12.9
8
3
5.96 3.82 1.71 72.4 5.32 4.29 1.53 57.6 5.82 4.01 1.67 69.0 6.27 3.78 1.80 79.9 6.67 3.58 1.91 90.5
4
5.70 3.69 1.23 37.2 5.06 4.15 1.09 29.3 5.53 3.92 1.19 35.0 5.96 3.66 1.28 40.7 6.35 3.47 1.37 46.2
5
5.41 3.54 0.93 21.5 4.75 4.03 0.82 16.5 5.25 3.75 0.90 20.2 5.69 3.53 0.98 23.7 6.08 3.33 1.05 27.1
6
5.06 3.43 0.73 13.0 4.44 3.92 0.64 10.0 4.96 3.62 0.71 12.5 5.40 3.37 0.77 14.8 5.77 3.17 0.83 17.0
7
4.76 3.27 0.59 8.5 4.12 3.76 0.51 6.4 4.61 3.50 0.57 8.0 5.05 3.24 0.62 9.5 5.40 3.04 0.66 10.9
9
3
5.54 3.65 1.59 62.5 4.88 4.13 1.40 48.4 5.39 3.83 1.54 59.1 5.85 3.59 1.68 69.6 6.23 3.41 1.78 78.9
4
5.23 3.52 1.12 31.3 4.59 4.01 0.99 24.1 5.07 3.72 1.09 29.5 5.51 3.50 1.18 34.8 5.91 3.28 1.27 39.9
5
4.95 3.37 0.85 18.0 4.24 3.92 0.73 13.2 4.80 3.59 0.82 16.8 5.22 3.35 0.90 20.0 5.62 3.13 0.97 23.1
6
4.62 3.25 0.66 10.9 3.92 3.79 0.56 7.8 4.46 3.48 0.64 10.1 4.94 3.19 0.71 12.4 5.32 2.99 0.76 14.4
7
4.28 3.09 0.53 6.8 3.66 / 0.45 5.0 4.13 3.32 0.51 6.4 4.57 3.09 0.56 7.8 4.95 2.85 0.61 9.2
10
3
5.08 3.46 1.46 52.6 4.38 3.97 1.25 39.0 4.88 3.69 1.40 48.4 5.37 3.45 1.54 58.7 5.79 3.22 1.66 68.2
4
4.77 3.33 1.03 26.1 4.05 3.89 0.87 18.7 4.61 3.57 0.99 24.3 5.07 3.31 1.09 29.5 5.45 3.10 1.17 34.0
5
4.46 3.22 0.77 14.6 3.79 / 0.65 10.5 4.27 3.45 0.73 13.4 4.75 3.18 0.82 16.6 5.17 2.96 0.89 19.5
6
4.15 3.08 0.60 8.8 3.59 / 0.52 6.6 3.96 3.32 0.57 8.0 4.44 3.01 0.64 10.0 4.83 2.81 0.69 11.9
7
3.79 2.95 0.47 5.4 3.38 / 0.42 4.3 3.61 3.20 0.44 4.9 4.07 2.92 0.50 6.2 4.52 2.67 0.55 7.6
11
3
4.59 3.31 1.32 42.9 3.89 / 1.12 30.8 4.43 3.52 1.27 39.8 4.89 3.29 1.40 48.6 5.32 3.05 1.53 57.6
4
4.30 3.19 0.92 21.2 3.70 / 0.80 15.7 4.13 3.39 0.89 19.5 4.60 3.13 0.99 24.2 5.03 2.93 1.08 28.9
5
3.97 3.07 0.68 11.6 3.52 / 0.61 9.1 3.79 3.31 0.65 10.5 4.28 3.00 0.74 13.4 4.70 2.79 0.81 16.2
6
3.62 2.94 0.52 6.7 3.30 / 0.47 5.5 3.48 3.16 0.50 6.2 3.95 2.90 0.57 7.9 4.36 2.65 0.62 9.7
7
3.22 2.84 0.40 3.9 3.11 / 0.38 3.6 3.11
/
0.38 3.6 3.58 2.76 0.44 4.8 4.01 2.49 0.49 6.0
12
3
4.10 3.15 1.18 34.3 3.60 / 1.03 26.4 3.91 3.40 1.12 31.1 4.43 3.10 1.27 39.8 4.84 2.89 1.39 47.6
4
3.80 3.04 0.82 16.5 3.43 / 0.74 13.5 3.61 3.28 0.78 14.9 4.11 2.99 0.88 19.4 4.55 2.76 0.98 23.7
5
3.47 2.94 0.60 8.8 3.28 / 0.56 7.9 3.29 3.17 0.57 7.9 3.79 2.88 0.65 10.5 4.22 2.63 0.73 13.0
6
3.08 2.84 0.44 4.8 3.05 / 0.44 4.7 3.05 2.99 0.44 4.7 3.44 2.76 0.49 6.0 3.87 2.48 0.55 7.6
7
2.73 / 0.34 2.8 2.84 / 0.35 3.0 2.81
/
0.35 3.0 3.00 2.62 0.37 3.4 3.51 2.34 0.43 4.6
13
3
3.59 3.01 1.03 26.2 3.32 / 0.95 22.5 3.38 3.27 0.97 23.3 3.90 2.95 1.12 30.9 4.36 2.72 1.25 38.7
4
3.28 2.90 0.71 12.3 3.17 / 0.68 11.5 3.17 3.11 0.68 11.5 3.59 2.88 0.77 14.7 4.05 2.59 0.87 18.7
5
2.93 2.86 0.50 6.3 2.95 / 0.51 6.4 2.96
/
0.51 6.4 3.27 2.74 0.56 7.9 3.73 2.47 0.64 10.2
6
2.66 / 0.38 3.6 2.76 / 0.39 3.9 2.76
/
0.39 3.9 2.89 2.64 0.41 4.2 3.36 2.34 0.48 5.8
7
2.43 / 0.30 2.2 2.53 / 0.31 2.4 2.53
/
0.31 2.4 2.53 2.48 0.31 2.4 2.94 2.20 0.36 3.2
