Midea MKA-1200R

MCAC-KTSM-2012-02 4-way cassette FCU
Capacity Tables 19
Heating Capacity:
For T3 models:
Remark:
Δt: Temperature Difference (℃) ; TH: Total Heating Capacity (kW); WF: Water Flow (m
3
/h); WPD: Water Pressure Drop
600
∆t
Air inlet temp. (20℃ DB)
Water inlet temp. (℃)
35 40 45 50 55 60 65 70
TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD
10 3.3 0.3 1.8 5.1 0.4 4.4 7.1 0.6 8.4 9.0 0.8 13.3 10.9 0.9 19.4 12.8 1.1 26.9 14.6 1.3 35.2 16.5 1.4 44.6
8 3.6 0.4 3.4 5.7 0.6 8.2 7.6 0.8 14.8 9.5 1.0 23.0 11.3 1.2 32.7 13.1 1.4 44.3 15.0 1.6 57.6 16.8 1.8 72.6
6 4.2 0.6 8.1 6.1 0.9 17.2 7.9 1.1 28.9 9.9 1.2 44.6 11.7 1.7 63.0 13.6 1.9 84.4 15.3 2.2 107.2 17.3 2.5 136.3
750
∆t
Air inlet temp. (20℃ DB)
Water inlet temp. (℃)
35 40 45 50 55 60 65 70
TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD
10 3.9 0.3 1.9 6.1 0.5 4.6 8.5 0.7 8.8 10.7 0.9 14.1 12.9 1.1 20.5 15.2 1.3 28.4 17.4 1.5 37.2 19.6 1.7 47.1
8 4.3 0.5 3.6 6.7 0.7 8.7 9.0 1.0 15.6 11.3 1.1 24.3 13.4 1.4 34.6 15.6 1.7 46.8 17.8 1.9 60.8 20.0 2.2 76.7
6 5.0 0.7 8.6 7.3 1.0 18.2 9.5 1.4 30.6 11.8 1.7 47.1 14.0 2.0 66.6 16.2 2.3 89.1 18.2 2.6 113.2 20.6 2.9 144.0
850
∆t
Air inlet temp. (20℃ DB)
Water inlet temp. (℃)
35 40 45 50 55 60 65 70
TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD
10 4.2 0.4 2.0 6.6 0.6 5.0 9.1 0.8 9.6 11.5 1.0 15.2 13.9 1.2 22.2 16.3 1.4 30.7 18.7 1.6 40.2 21.0 1.8 51.0
8 4.6 0.5 3.9 7.2 0.8 9.4 9.7 1.0 16.9 12.1 1.2 26.3 14.4 1.5 37.4 16.7 1.8 50.6 19.1 2.1 65.9 21.4 2.3 83.1
6 5.4 0.8 9.3 7.8 1.1 19.7 10.1 1.5 33.1 12.6 1.6 51.0 15.0 2.1 72.1 17.3 2.5 96.5 19.5 2.8 122.5 22.0 3.2 155.9
950
∆t
Air inlet temp. (20℃ DB)
Water inlet temp. (℃)
35 40 45 50 55 60 65 70
TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD
10 4.7 0.4 2.4 7.4 0.6 5.9 10.2 0.9 11.2 12.8 1.1 17.9 15.5 1.3 26.1 18.3 1.6 36.2 20.9 1.8 47.3 23.5 2.0 60.0
8 5.2 0.6 4.6 8.1 0.9 11.1 10.8 1.2 19.9 13.5 1.3 31.0 16.1 1.7 44.0 18.7 2.0 59.6 21.4 2.3 77.5 24.0 2.6 97.7
6 6.0 0.9 10.9 8.8 1.3 23.2 11.4 1.6 38.9 14.1 1.7 60.0 16.8 2.4 84.8 19.4 2.8 113.5 21.9 3.1 144.2 24.7 3.5 183.4
1200
∆t
Air inlet temp. (20℃ DB)
Water inlet temp. (℃)
35 40 45 50 55 60 65 70
TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD
10 5.9 0.5 3.3 9.3 0.8 8.0 12.9 1.1 15.4 16.3 1.4 24.5 19.7 1.7 35.8 23.2 2.0 49.5 26.5 2.3 64.8 29.8 2.6 82.2
8 6.6 0.7 6.3 10.3 1.1 15.2 13.7 1.5 27.3 17.1 1.7 42.4 20.4 2.2 60.3 23.8 2.6 81.6 27.1 2.9 106.2 30.5 3.3 133.9
6 7.6 1.1 15.0 11.1 1.6 31.7 14.4 2.1 53.3 17.9 2.3 82.2 21.3 3.1 116.2 24.6 3.5 155.5 27.7 4.0 197.5 31.3 4.5 251.3
