4-way cassette FCU MCAC-KTSM-2012-02
20 Capacity Tables
1500
∆t
Air inlet temp. (20℃ DB)
Water inlet temp. (℃)
35 40 45 50 55 60 65 70
TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD TH WF WPD
10 6.0 0.5 2.0 9.4 0.8 4.9 13.0 1.1 9.4 16.4 1.4 15.0 19.8 1.7 21.9 23.3 2.0 30.3 26.6 2.3 39.6 30.0 2.6 50.2
8 6.6 0.7 3.8 10.3 1.1 9.3 13.8 1.5 16.7 17.2 1.9 25.9 20.6 2.2 36.9 23.9 2.6 49.9 27.3 2.9 64.9 30.6 3.3 81.8
6 7.7 1.1 9.1 11.2 1.6 19.4 14.5 2.1 32.6 18.0 2.6 50.2 21.4 3.1 71.0 24.8 3.5 95.0 27.9 4.0 120.7 31.5 4.5 153.5
Heating capacity modification coefficient table:
Speed
200 300 400 500 600 800
TH TH TH TH TH TH
High 1 1 1 1 1 1
Mid 0.79 0.78 0.79 0.8 0.78 0.79
Low 0.64 0.65 0.63 0.65 0.64 0.66
Altitude modification coefficient table:
Altitude TC SC TH
500 0.98 0.95 0.95
1000 0.97 0.91 0.91
1500 0.95 0.86 0.86
2000 0.94 0.82 0.82
2500 0.93 0.78 0.78
3000 0.91 0.74 0.7
