Midea MLE41N1AWW

Service manual for Dryer Machine
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 32 －
6. Remove the heater assy
6.1 Pull out all the
terminals;
6.2 Remove the screw that
is used to fix the heater
assy;
6.3 Take down the heater
assy;
6.4 Remove the
thermostat;
6. Remove the burner assy
(Gas model only)
6.1 Pull out all the
terminals;
6.2 Remove the 4 screws
fixing the burner assy;
