Midea MLE41N1AWW

Service manual for Dryer Machine
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 45 －
GAS MODEL
No.
Part Name
Quantity
1.1
Door Handle
1.0
1.2
Door Cover
1.0
1.3
Door Cover Back
1.0
1.4
Door Gasket
1.0
1.5
Door Hinge Assembly
2.0
1.6
Fixed Seat
2.0
2.1
Front Panel
1.0
2.2
Cover Switch
1.0
2.3
Front Panel Cover (2)
1.0
2.4
Door Pin
1.0
2.5
Front Panel Cover (1)
1.0
2.6
Fireproofing Plate
2.0
3.1
Front Air Flue Assembly
1.0
3.2
Lint Filter Assembly
1.0
3.3
Sponge
1.0
3.4
Front Support Assembly
1.0
3.5
Nut
2.0
3.6
Flat Gasket
2.0
3.7
Wheel Assembly
2.0
3.8
Humidity Sensor Cover
2.0
3.9
Filter Lint Cover
1.0
3.10
Fuse Assembly
1.0
4
Base Subassembly
1.0
5.1
Volute
1.0
5.2
Thermostate
1.0
5.3
Nut
1.0
5.4
Impeller Assembly
1.0
5.5
Volute Cover
1.0
5.6
Temperature Sensor
1.0
5.7
Single phase asynchronous motor
1.0
5.8
Clip Spring
2.0
5.9
Support For Tensioner Pulley Assembly
1.0
5.10
Spring
1.0
5.11
Screw
1.0
5.12
Safety Switch
1.0
5.13
Motor Support
1.0
6
Adjustable Foot Assembly
2.0
7
Heater Assembly
1.0
7.1
Combustion Chamber
1.0
7.2
Thermostate
1.0
