20cm
30cm
20cm
min85cm
0cm
INSTALLATION
1. Select level surfaces that provide enough open space for the intake and/or outlet
vents.
The rear surface of appliance shall be placed against a wall.
A minimum clearance of 7.9inches (20cm) is required between the oven
and any adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12 inches (30cm) above the oven.
(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage the oven.
(4) Place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your radio or TV
reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the
frequency is the same as the voltage
and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing
appliance. If installed near or over a heat source, the oven could be damaged
and the warranty would be void.
CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the inside of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighboring parts must be cleaned carefully with a damp
cloth when they are dirty.
Countertop Installation
Remove all packing material and accessories. Examine the oven for any damage such
as dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to
protect the magnetron.
