Specifications MCAC-UTSM-2008-11
10 Indoor Units
2. Specifications
Model MCA-12HRN1 MCA-18HRN1
Code 220042002960 220042001870
Power supply V-ph-Hz
220~240-1-50 220~240-1-50
Cooling
Capacity kW 3.2 5.3
Input W 1100 1900
Heating
Capacity kW 4 6
Input W 1050 1900
Indoor fan motor
Model YDK45-4F YDK45-4F
Brand Welling Welling
Input W 56.7/51.5/44.4 56.7/51.5/44.4
Capacitor uF 1.5uF/450V 2.5uF/450V
Speed(Hi/Mi/Lo) r/min 930/845/680 930/845/680
Indoor coil
Number of rows 2 2
Tube pitch(a)×row pitch(b) mm 21×13.37 21×13.37
Fin spacing mm 1.4 1.4
Fin type (code) Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type mm φ7 Inner grooved copper tube
φ7 Inner grooved copper tube
Coil length × height × width
mm 1215×210×26.74 1215×210×26.74
Number of circuits 5 5
Indoor air flow (Hi/Mi/Lo) m
3
/h 680/600/400 860/760/500
Indoor noise level (sound pressure) dB(A) 41/38/35 42.5/39.4/35.8
Indoor unit
Dimension (W×H×D)(body)
mm 580×254×580 580×254×580
Packing (W×H×D)(body) mm 750×340×745 750×340×745
Dimension (W×H×D)(panel)
mm 650×30×650 650×30×650
Packing (W×H×D)(panel) mm 715×115×715 715×115×715
Net/Gross weight(body) kg 21/28 21/27
Net/Gross weight(panel) kg 3/5 3/5
Refrigerant type R410A R410A
Design pressure MPa 4.4/2.6 4.4/2.6
Refrigerant piping
Liquid side/ Gas side mm φ6.4/φ12.7 φ6.4/φ12.7
Drainage water pipe diameter mm ODφ25 ODφ25
Connection wiring
Power wiring mm
2
3×2.5 3×2.5
Strong electric signal wiring
mm
2
5×2.5 5×2.5
Weak electric signal wiring mm
2
1-core shield wire 1×0.5 1-core shield wire 1×0.5
Controller R11HG/E(standard) R11HG/E(standard)
Operation temperature ℃ 17-30 17-30
Notes: 1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB;
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB;
3. Actual noise level may differ, depending on the room structure, etc, since these noise values are from an anechoic
room.
