Remote Controller Illustration
Example: Setting the unit to turn on after 6 hours, operate for 2 hours, then turn off
(see the figure below).
Yourremote display
Timer is set to turn ON
6 hours from the current time
Timer is set to turn OFF
8 hours from the current time
Current
time 1PM
2PM 3PM
4PM 5PM
6PM 7PM 8PM 9PM
Timer starts
Unit turns Unit turns
ON
OFF
6 hours later
8 hours later
Timer on
Timer off
