10
5. Refrigerant Cycle Diagram
The figure below is a brief description of the important components and their function in what is called
the refrigeration system.
This will help to understand the refrigeration cycle and the flow of the refrigerant in the cooling cycle.
LIQUI
D SIDE
GAS S
IDE
EVAPO
RATOR
CONDENSER
COMPRESSOR
CAPILIARY TUBE
