Midea R410A Tropical ClimaCreator Series Rooftop Package 50Hz MCAC-RTT5T-201707
111
Main power wiring to the unit control wiring between the control center and the unit, and
earth wiring are required in the field.
The following components are required: main power fuses; conduit coupling.
Wire and fuse sizes should be selected in accordance with national and standard, taking the
designed maximum current shall be the total of the compressor maximum current,
condenser fan motor current and evaporator fan motor current.
The wire size between the wired controller and the unit should be determined according to
the following table, because the 24V power source is applied to the control circuit.
Wiring length between wired controller and unit (One way)
Main power supply parameters:
