Midea MRC-24CWN1-M13L User Manual

13
Table 6-3: 13 SEER Physical Data
MRC-24CWN1-M13L
Nominal Tonnage 2.0 2.0 3.0 3.0 4.0 4.0
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu)
23,935 23,735 35,963 35,563 48,813 48,313
ARI net capacity (Btu) 23,000 22,800 34,800 34,000 47,000 46,500
EER 10.85 10.85 10.40 10.10 10.90 10.80
SEER 13
13 13 13 13 13
Nominal CFM 730 730 1220 1220 1600 1600
S
ystem power (kW) 2.0 2.0 3.2 3.2 4.22 4.22
Refrigerant
type R410A R410A R410A R410A R410A R410A
Refr
igerant charge (lb-oz) 3-15 3-15 4-14 5-12 8-3 8-6
ARI HEATING PERFORMANCE
47
O
F Capacity rating (Btu)
— 22,000 — 34,800 — 47,500
System power (kW) — 1.85 — 2.80 — 3.95
17
O
F Capacity rating (Btu)
— 11,200 — 19,000 — 26,500
System power (kW) — 1.60 — 2.50 — 3.40
HSPF (BTU/Watts-hr.) — 7.7 — 7.7 — 7.7
DIMENSIONS (Inches)
Length 51-25/64 51-25/64 51-25/64 51-25/64 57-61/64 57-61/64 57-61/64 57-61/64
Width 37-23/32 37-23/32 37-23/32 37-23/32 42 42
Height 24-13/16 24-13/16 24-13/16 24-13/16 33-3/64 33-3/64 33-3/64 33-3/64
OPERATING WT. (lbs) 304 309 335 340 445 454
COMPRESSORS
Ty
pe Rotary
Quantity 1 1 1 1 1 1
CO
NDENSER COIL DATA
Face area (Sq. Ft) 10.17 10.17 10.17 10.17 15.77 15.77
Rows 1.5
1.5
2 2 2 2
Fins per inch 20 20 20 20 20 20
Tube diameter(inch) 9/32 9/32 9/32 9/32 9/32 9/32
Circuitry type interlaced i
nterlaced
i
nterlaced
i
nterlaced
i
nterlaced
i
nterlaced
EVAPORATOR COIL DATA
Face area (Sq. Ft) 3.36 3.36 3.36 3.36 6.43 6.43
Rows 3 3 4 4 3 3
Fins per inch 17 17 17 17 17 17
Tube diameter(inch) 9/32 9/32 9/32 9/32 9/32 9/32
Circuitry type interlaced interlaced interlaced interlaced interlaced interlaced
Refrigerant control Orifice
Orifice Orifice Orifice Orifice Orifice
CONDENSER FAN DATA
Fan diameter (inch) 22-3/64 22-3/64 22-3/64 22-3/64 23-5/8 23-5/8
Ty
pe Prop Prop Prop Prop Prop Prop
Drive type Direct D
irect
D
irect
D
irect
D
irect
D
irect
No.
speeds 1 1 1 1 1 1
Num
ber of motors 1 1 1 1 1 1
Motor HP each 1/12 1/12 1/6 1/6 1/3 1/3
RPM 1075 1075 825 825 1075 1075
Nominal total CFM 1960 1960 2565 2565 3960 3960
DIRECT
DRIVE EVAP FAN DATA
Quantity 1 1 1 1 1 1
Fan Size (Inch) 9×9 9×9 9×9 9×9 10×10 10×10
Ty
pe Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
No. speeds 3 3 3 3 3 3
Motor HP each 1/4 1/4 3/4 3/4 3/4 3/4
RPM 1075 1075 1075 1075 1075 1075
Motor frame size 48 48 48 48 48 48
FILTERS
(No.) Size Recommended in. (1) 22×14×1 (1) 22×14×1 (1) 22×14×1 (1) 22×14×1 (1) 22×14×1 (1) 22×14×1
Models
Component
5.0 5.0
58,075 58,075
56,000 56,000
10.55
10.40
13 13
2000 2000
5.27 5.27
R410A R410A
8-13 9-1
— 57,500
— 4.65
— 31,000
— 4.05
— 7.7
42 42
463 472
Scroll 1-spdScroll 1-spdScroll 1-spdScroll 1-spdScroll 1-spd Scroll 1-spd
11
15.77 15.77
2.5 2.5
20 20
9/32 9/32
interlaced interlaced
6.43 6.43
44
17 17
9/32 9/32
interlaced interlaced
Orifice Orifice
23-5/8 23-5/8
Prop Prop
Direct Direct
11
11
1/3 1/3
1075 1075
3960 3960
11
10×10 10×10
Centrifugal Centrifugal
33
11
1075 1075
48 48
(1) 22×14×1 (1) 22×14×1
MRC-36CWN1-M13L
MRC-48CWN1-M13L
MRC-60CWN1-M13L
Rotary
MRC-24HWN1-M13L
MRC-36HWN1-M13L
MRC-48HWN1-M13L
MRC-60HWN1-M13L
