Table 6-2: 13 SEER Cooling only W/Without Electric Heat
1. Minimum Circuit Ampacity.
2. Maximum Over Current Protection per Standard UL 1995.
3. Fuse or HACR circuit breaker size installed at factory or field installed.
Table 6-1: 13 SEER Heat Pump W/Without Electric Heat
024T: GMCC compressor
036L/048L/060L: LG compressor
024T: GMCC compressor
036L/048L/060L: LG compressor
OD Fan
Motors
(each)
Supply
Blower
Motor
RLA LRA MCC FLA FLA Model kW Stages Amps
None - - None 14.5 20
EHK-05E 3.8/5 1 18.1/20.8 32.6/40.5 40/45
EHK-08E 5.6/7.5 1 27.1/31.3 41.6/53.6 50/60
EHK-08E 5.6/7.5 1 27.1/31.3 55.2/60.5 60/70
EHK-10E 7.5/10 1 36.1/41.7 50.6/66.6 60/70
None - - None 21.3 30
EHK-05E 3.8/5 1 18.1/20.8 44.0/47.3 50/50
EHK-10E 7.5/10 1 36.1/41.7 66.5/73.5 70/80
EHK-15E 11.3/15 2 54.2/62.5 89.1/99.5 90/100
None - - None 29.1 45
EHK-05E 3.8/5 1 18.1/20.8 47.2/55.1 60/60
EHK-08E 5.6/7.5 1 27.1/31.3 56.2/68.3 70/80
EHK-10E 7.5/10 1 36.1/41.7 65.2/81.3 80/90
EHK-15E 11.3/15 2 54.2/62.5 83.3/107.3 100/110
EHK-20E 15/20 2 72.2/83.3 101.3/133.3 125/150
None - - None 32.4 50
EHK-05E 3.8/5 1 18.1/20.8 50.5/58.4 70/70
EHK-08E 5.6/7.5 1 27.1/31.3 59.5/71.5 80/80
EHK-10E 7.5/10 1 36.1/41.7 68.5/84.5 90/90
EHK-15E 11.3/15 2 54.2/62.5 86.6/110.5 100/125
EHK-20E 15/20 2 72.2/83.3 104.6/136.5 125/150
Electric Heat Option
Max Fuse2/
Breaker3 Size
(Amps)
Compressors (each)
18.7A
0.95A
2.84A
060L
(5.0)
208/230-1-60 21.5A
Volt
Size
(Tons)
MCA1 (Amps)
036L
(3.0)
208/230-1-60
14.0A
70A
024T
(2.0)
208/230-1-60
9.7A
34.8A
15.1A
0.61A
1.71A
048L
(4.0)
208/230-1-60
19.0A
100A
29.6A
1.68A
3.66A
125A 33.5A 1.68A 3.82A
OD Fan
Motors
(each)
Supply
Blower
Motor
RLA LRA MCC FLA FLA Model kW Stages Amps
None - - None 14.5 20
EHK-05E 3.8/5 1 18.1/20.8 24.8/28.2 25/30
EHK-08E 5.6/7.5 1 27.1/31.3 36.1/41.3 40/45
EHK-08E 5.6/7.5 1 27.1/31.3 37.5/42.7 40/45
EHK-10E 7.5/10 1 36.1/41.7 47.3/54.3 50/60
None - - None 21.3 30
EHK-05E 3.8/5 1 18.1/20.8 26.2/29.6 30/30
EHK-10E 7.5/10 1 36.1/41.7 48.7/55.7 50/60
EHK-15E 11.3/15 2 54.2/62.5 71.3/81.7 80/90
None - - None 29.1 45
EHK-05E 3.8/5 1 18.1/20.8 27.2/30.6 30/40
EHK-08E 5.6/7.5 1 27.1/31.3 38.5/43.7 40/45
EHK-10E 7.5/10 1 36.1/41.7 49.7/56.7 50/60
EHK-15E 11.3/15 2 54.2/62.5 72.4/82.7 80/90
EHK-20E 15/20 2 72.2/83.3 94.9/108.7 100/110
None - - None 32.4 50
EHK-05E 3.8/5 1 18.1/20.8 27.4/30.8 30/40
EHK-08E 5.6/7.5 1 27.1/31.3 38.7/43.9 40/45
EHK-10E 7.5/10 1 36.1/41.7 49.9/56.9 50/60
EHK-15E 11.3/15 2 54.2/62.5 75.6/82.9 80/90
EHK-20E 15/20 2 72.2/83.3 95.1/108.9 100/110
Electric Heat Option
Max Fuse2/
Breaker3 Size
(Amps)
Compressors (each)
18.7A
0.95A
2.84A
060L
(5.0)
208/230-1-60 21.5A
Volt
Size
(Tons)
MCA1 (Amps)
036L
(3.0)
208/230-1-60
14.0A
70A
024T
(2.0)
208/230-1-60
9.7A
34.8A
15.1A
0.61A
1.71A
048L
(4.0)
208/230-1-60
19.0A
100A
29.6A
1.68A
3.66A
125A 33.5A 1.68A 3.82A
