RooftopClimaCreatorseries DM16‐01.01.27en
Service manual 105
 Attach the supply and return air ducts to the unit.
 Insulate any ductwork outside of the structure with at least 2 inches of insulation and
weatherproof. There must be a weatherproof seal where the duct enters the structure.
 Complete the installation.
5. Condensate drainage
Model X value (mm) Model X value (mm)
MRCT-062CWN1-R(C) 20 ≤ X ≤ 40 MRCT-075CWN1-R(C) 20 ≤ X ≤ 40
MRCT-085CWN1-R(C) 20 ≤ X ≤ 40 MRCT-100CWN1-R(C) 20 ≤ X ≤ 40
MRCT-125CWN1-R(C) 20 ≤ X ≤ 40 MRCT-150CWN1-R(C) 20 ≤ X ≤ 40
MRCT-175CWN1-R(C) 20 ≤ X ≤ 40 MRCT-200CWN1-R(C) 20 ≤ X ≤ 40
MRCT-250CWN1-R(C) 20 ≤ X ≤ 40 MRCT-300CWN1-R(C) 0 ˂ X ≤ 20
