RooftopClimaCreatorseries DM16‐01.01.27en

Service manual 127

Appendix: - EHK (Electrical Heater Kits)

1. EHK Parameter

Model

EHK

Controlling

Box

EH Duct Input FLA MCA MOP

MRCT-062CWN1-R(C)

EHK-BOX-A EHK-15F(D) 15kW 22.7A 28.4A 35A

MRCT-075CWN1-R(C)

EHK-BOX-A EHK-15F(D) 15kW 22.7A 28.4A 35A

MRCT-085CWN1-R(C)

EHK-BOX-A EHK-20F(D) 20kW 30.3A 37.9A 40A

MRCT-100CWN1-R(C)

EHK-BOX-A EHK-20F(D) 20kW 30.3A 37.9A 40A

MRCT-125CWN1-R(C)

EHK-BOX-A EHK-20F(D) 20kW 30.3A 37.9A 40A

EHK-BOX-B EHK-30F(D) 30kW 45.5A 56.9A 60A

MRCT-150CWN1-R(C)

EHK-BOX-A EHK-20F(D) 20kW 30.3A 37.9A 40A

EHK-BOX-B EHK-30F(D) 30kW 45.5A 56.9A 60A

MRCT-175CWN1-R(C)

EHK-BOX-B EHK-40C(D) 40kW 60.6A 75.8A 80A

MRCT-200CWN1-R(C)

EHK-BOX-B EHK-40C(D) 40kW 60.6A 75.8A 80A

MRCT-250CWN1-R(C)

EHK-BOX-B EHK-40D(D) 40kW 60.6A 75.8A 80A

MRCT-300CWN1-R(C)

EHK-BOX-B EHK-40D(D) 40kW 60.6A 75.8A 80A

Notes:

1. EHK (Electrical heater kits) includes controlling box and EH (Electrical heater) duct. It is

independently packaged, and should be fixed with rooftop package unit on-site.

2. MRCT-125CWN1-R(C) & MRCT-150CWN1-R(C) can be customized with 20kW EHK or 30kW

electrical heater kits;

3. FLA: Full Load Amps;

4. MCA: Min. Current Amps;

5. MOP: Max. Over Protector;

6. The values of FLA, MCA and MOP are based on the power supply of 380V.
