Midea MS9A-05CR-QD0 - Page 12

10
L
R
H
Model
R(mm)
L(mm)
H(mm)
Dimension of installation hole(mm)
MS9A-05CR-QD0
111.5 100 45
￠65
MS9A-07CR-QB6
MS9A-07HR-QB6
MS9A-09CR-QB6
MS9A-09HR-QB6
MS9A-09CR-QB6(A)
151
100 45
MS9A-09CR-QC0
MS9A-09CR-QC4(A)
MS9A-12CR-QB6
MS9A-12HR-QB4
MS9A-12HR-QB6
MS9A-18CR-QC2
118.5 100 45
MS9A-18CR-QB8
MS9A-18CR-QC4(A)
MS9A-18CR-QC0(A)
MS9A-22CR-QC0
MS9A-22CR-QB8
MA9A-24HR-QB4W
MA9A-24HR-QB4W
