16
6.2 Wiring diagram
6.2.1 Cooling only
6.2.1.1 MSE-07CR, MSE-09CR MSE-12CR
1
2(N)
Y&G
BLUE
S
RED
C
BLACK
R
BLACK
COMPRESSOR
CAPACITOR
FAN
MOTOR
BLUE
RED
RED
RED
BLACK
Y&G
INDOOR
UNIT
OUTDOOR
UNIT
