17
6.2.1.2 MSE-18CR
INDOOR UNIT
COMPRESSOR
CAPACITOR
COMPRESSOR
Y/G
WHITE
S
BLUE
R
C
OVERLOAD
RELAY
RED
OUTDOOR UNIT
CAPACITOR
FAN
FAN
MOTOR
BLUE
RED
BLACK
Y&G
BLACK
BLACK
