Service manual
- 9 -
MSG-16CRN2 MSG-16HRN2 MSG18CRN2
Ph-V-Hz
1, 220-240V~,50Hz 220-240V~,50Hz 220-240V~,50Hz
Capacity Btu/h 16000 16000 17000
Input W 1810 1820 1890
Rated current A 8.3 8.3 8.5
EER Btu/w.h 8.8, 2.6 8.8, 2.6 9.0, 2.63
Capacity Btu/h 18000
Input W 1660
Rated current A 7.6
COP W/W 3.2
A131313
A414141
Model PG295*2CS-4KU1 PG295*2CS-4KU1 PG295*2CS-4KU1
Type Rotary Rotary Rotary
Brand GD Toshiba GD Toshiba GD Toshiba
Capacity Btu/h 18083 18083 18083
Input W 1760 1760 1760
Rated current(RLA) A 8.5 8.5 8.5
Locked rotor Amp(LRA) A 40 40 40
Thermal protector Internal Internal Internal
Capacitor uF 35UF/370V 35UF/370V 35UF/370V
Refrigerant oil ml 750 750 750
Model
RPG25 RPG25 RPG25
Brand WELLING WELLING WELLING
Input W 53 53 53
Capacitor uF 1.5uF/450V 1.5uF/450V 1.5uF/450V
Speed(hi/mi/lo) r/min 1260/1100/1000 1260/1100/1000 1260/1100/1000
m3/h
800/770/740 800/770/740 800/770/740
dB(A) 42/40/38 42/40/38 42/40/38
Model
YDK36-6 YDK36-6 YDK36-6
Brand WELLING WELLING WELLING
Input W
96 96 96
Capacitor uF
2.5μF/450V 2.5μF/450V
2.5μF/450V
Speed r/min
900 900 900
m
3
h
1900 1900 1900
dB(A) 53
53 53
g 1380
1380 2200
MPa 2.8
2.8 2.8
Liquid side/ Gas side mm
Ф6.35/Ф12.7 Ф6.35/Ф12.7 Ф6.35/Ф12.7
Max. refrigerant pipe length m 10 10 10
Max. difference in level m 5 5 5
℃
17-30 17-30 17-30
℃
18-45 -7 - 45 18-45
m
2
25-35 25-35 30-40
Model
Power supply
Cooling
Heating
Max. current
Starting current
Compressor
Indoor
fan motor
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R407C
Design pressure
Refrigerant
piping
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
