Page 9
Indoor Unit
Installation
Air inlet
Display panel
Air outlet
grille
Louver
Installation part
Indoor Unit Installation
4
Indoor Unit Parts
Fig. 4.1
Safety Precautions
WARNING
• Securely install the indoor unit on a
structure that can sustain its weight. If the
structure is too weak, the unit may fall and
cause personal injury, unit and property
damage, or death.
• DO NOT install the indoor unit in a
bathroom or laundry room as excessive
moisture can short the unit and corrode the
wiring.
CAUTION
• Install the indoor and outdoor units, cables,
and wires at least 1m (3.2’) from televisions
and radios to prevent static or image
distortion. Depending on the appliances,
a 1m (3.2’) distance may not be sucient.
•
If the indoor unit is installed on metal,
it must be electrically grounded.
