Midea VC Pro Series Engineering Data Book
Table 2-8.22: 26HP cooling part load performance
Part
load
Outdoor
temperature (°C
DB)
Indoor temperature(°C DB/WB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
100%
-5
49.28
7.35
58.66
8.85
68.31
10.53
73.00
11.28
77.69
12.24
87.34
13.95
92.29
14.55
-2
49.28
7.44
58.66
8.96
68.31
10.65
73.00
11.49
77.69
12.40
87.34
14.11
92.29
14.65
0
49.28
7.51
58.66
9.06
68.31
10.76
73.00
11.63
77.69
12.52
87.34
14.34
92.29
14.81
2
49.28
7.66
58.66
9.18
68.31
10.88
73.00
11.78
77.69
12.66
87.34
14.55
92.29
15.05
4
49.28
7.72
58.66
9.27
68.31
11.04
73.00
11.96
77.69
12.82
87.34
14.70
92.29
15.21
6
49.28
7.83
58.66
9.45
68.31
11.19
73.00
12.17
77.69
13.01
87.34
14.91
92.29
15.44
8
49.28
7.98
58.66
9.59
68.31
11.39
73.00
12.31
77.69
13.22
87.34
15.14
92.29
15.70
10
49.28
8.07
58.66
9.78
68.31
11.57
73.00
12.52
77.69
13.47
87.34
15.39
92.29
15.93
12
49.28
8.20
58.66
9.97
68.31
11.79
73.00
12.74
77.69
13.72
87.34
15.67
90.99
16.05
14
49.28
8.36
58.66
10.16
68.31
12.02
73.00
12.99
77.69
13.97
87.34
15.99
89.94
16.24
16
49.28
8.52
58.66
10.34
68.31
12.27
73.00
13.24
77.69
14.26
86.82
16.18
88.64
16.43
18
49.28
8.67
58.66
10.53
68.31
12.49
73.00
13.50
77.69
14.54
85.78
16.71
87.60
16.84
20
49.28
8.83
58.66
10.75
68.31
12.87
73.00
14.19
77.69
15.58
84.47
17.50
86.29
17.66
21
49.28
8.92
58.66
10.85
68.31
13.34
73.00
14.70
77.69
16.12
83.95
17.91
85.78
18.07
23
49.28
9.14
58.66
11.57
68.31
14.29
73.00
15.74
77.69
17.28
82.91
18.73
84.47
18.89
25
49.28
9.74
58.66
12.36
68.31
15.29
73.00
16.87
77.69
18.51
81.61
19.55
83.42
19.71
27
49.28
10.41
58.66
13.18
68.31
16.34
73.00
18.04
77.69
19.81
80.30
20.37
82.13
20.56
29
49.28
11.07
58.66
14.07
68.31
17.44
73.00
19.27
77.43
21.03
79.26
21.22
81.08
21.38
31
49.28
11.79
58.66
15.01
68.31
18.61
73.00
20.56
76.39
21.86
77.96
22.04
79.77
22.23
33
49.28
12.52
58.66
15.99
68.31
19.84
73.00
21.95
75.09
22.67
76.91
22.86
78.74
23.08
35
49.28
13.31
58.66
17.00
68.31
21.16
73.00
23.40
73.78
23.49
75.61
23.71
77.43
23.91
37
49.28
14.16
58.66
18.10
68.31
22.55
71.69
24.22
72.74
24.35
74.56
24.56
76.13
24.76
39
49.28
15.04
58.66
19.24
68.31
24.00
70.65
25.04
71.43
25.17
73.26
25.39
75.09
25.64
41
49.28
15.74
58.66
19.94
68.31
24.88
69.55
25.22
70.88
25.55
71.99
25.98
73.99
26.17
43
48.95
16.34
58.28
20.50
67.86
25.17
68.01
25.34
69.91
25.63
71.94
25.98
72.21
26.28
46
48.95
17.27
58.28
21.43
67.86
25.60
66.56
25.69
69.55
26.09
71.33
26.38
70.76
26.63
48
48.95
18.03
58.28
22.19
67.86
25.64
63.82
25.98
69.44
26.56
66.98
26.66
69.21
26.88
50
48.37
18.13
57.58
22.29
67.08
25.76
63.31
26.10
68.75
26.66
66.21
26.80
68.46
27.01
52
47.79
18.18
56.71
22.39
66.21
25.85
62.15
26.20
67.66
26.80
65.34
26.89
67.66
27.10
55
46.92
18.29
55.84
22.55
65.05
26.06
61.28
26.41
66.79
26.96
64.18
27.06
66.50
27.31
75%
-5
37.02
5.01
44.31
5.87
51.32
6.66
54.97
7.14
58.61
7.62
65.63
8.71
72.92
10.02
-2
37.02
5.05
44.31
5.90
51.32
6.70
54.97
7.27
58.61
7.75
65.63
8.85
72.92
10.15
0
37.02
5.08
44.31
5.98
51.32
6.83
54.97
7.41
58.61
7.89
65.63
9.03
72.92
10.29
2
37.02
5.10
44.31
6.01
51.32
6.94
54.97
7.55
58.61
8.03
65.63
9.22
72.92
10.46
4
37.02
5.17
44.31
6.16
51.32
7.10
54.97
7.68
58.61
8.21
65.63
9.37
72.92
10.70
6
37.02
5.26
44.31
6.27
51.32
7.27
54.97
7.93
58.61
8.40
65.63
9.54
72.92
10.91
8
37.02
5.35
44.31
6.45
51.32
7.44
54.97
8.05
58.61
8.58
65.63
9.81
72.92
11.11
10
37.02
5.46
44.31
6.55
51.32
7.63
54.97
8.22
58.61
8.81
65.63
10.01
72.92
11.25
12
37.02
5.59
44.31
6.64
51.32
7.79
54.97
8.38
58.61
8.96
65.63
10.20
72.92
11.47
14
37.02
5.69
44.31
6.77
51.32
7.91
54.97
8.50
58.61
9.12
65.63
10.38
72.92
11.68
16
37.02
5.78
44.31
6.89
51.32
8.07
54.97
8.68
58.61
9.30
65.63
10.57
72.92
11.90
18
37.02
5.87
44.31
7.02
51.32
8.22
54.97
8.84
58.61
9.46
65.63
10.79
72.92
12.15
20
37.02
5.96
44.31
7.14
51.32
8.38
54.97
8.99
58.61
9.64
65.63
11.00
72.92
12.49
21
37.02
6.03
44.31
7.20
51.32
8.44
54.97
9.09
58.61
9.74
65.63
11.16
72.92
12.92
23
37.02
6.12
44.31
7.32
51.32
8.62
54.97
9.40
58.61
10.23
65.63
11.96
72.92
13.85
25
37.02
6.24
44.31
7.63
51.32
9.18
54.97
10.04
58.61
10.91
65.63
12.79
72.92
14.80
27
37.02
6.61
44.31
8.13
51.32
9.80
54.97
10.69
58.61
11.65
65.63
13.66
72.92
15.82
29
37.02
7.02
44.31
8.62
51.32
10.41
54.97
11.40
58.61
12.39
65.63
14.56
72.92
16.91
31
37.02
7.42
44.31
9.15
51.32
11.10
54.97
12.11
58.61
13.20
65.63
15.51
72.92
18.02
33
37.02
7.88
44.31
9.74
51.32
11.81
54.97
12.89
58.61
14.06
65.63
16.53
72.92
19.22
35
37.02
8.34
44.31
10.32
51.32
12.52
54.97
13.72
58.61
14.96
65.63
17.62
72.92
20.49
37
37.02
8.81
44.31
10.94
51.32
13.32
54.97
14.56
58.61
15.92
65.63
18.76
72.92
21.82
39
37.02
9.33
44.31
11.59
51.32
14.12
54.97
15.48
58.61
16.91
65.63
19.93
72.92
23.24
41
37.02
9.75
44.31
12.00
51.32
14.54
54.97
16.00
58.61
17.42
65.63
20.76
72.92
24.27
43
36.78
10.47
44.02
12.74
50.99
15.03
54.61
16.74
58.23
17.82
65.20
21.37
72.44
24.86
46
36.78
10.70
44.02
13.01
50.99
15.35
54.61
17.02
58.23
18.70
65.20
22.53
72.44
25.81
48
36.78
10.90
44.02
13.09
50.99
15.54
54.61
17.31
58.23
19.22
65.20
23.58
72.44
26.44
50
36.53
11.05
43.63
13.22
50.46
15.59
54.17
17.38
57.56
19.29
64.38
23.68
71.81
26.57
52
35.93
11.10
43.03
13.26
49.86
15.63
53.24
17.46
56.63
19.38
63.46
23.76
70.61
26.65
55
35.28
11.14
42.10
13.34
48.93
15.77
52.32
17.56
55.70
19.51
62.53
23.92
69.68
26.85
Abbreviations:
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Table continued on next page …
