Midea MVC-335WV2GN1 User Manual

VC Pro VRF 50/60Hz
129
Part 2 - Outdoor Unit Engineering Data
Table 2-8.22: 26HP cooling part load performance (continued)
Part
load
Outdoor
temperature (°C
DB)
Indoor temperature(°C DB/WB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
50%
-5
24.80
2.94
29.62
3.40
34.45
3.97
36.87
4.23
39.28
4.56
44.11
5.13
48.93
5.88
-2
24.80
2.95
29.62
3.46
34.45
4.04
36.87
4.29
39.28
4.61
44.11
5.20
48.93
5.92
0
24.80
3.00
29.62
3.50
34.45
4.09
36.87
4.34
39.28
4.69
44.11
5.28
48.93
5.99
2
24.80
3.05
29.62
3.58
34.45
4.17
36.87
4.43
39.28
4.75
44.11
5.39
48.93
6.07
4
24.80
3.14
29.62
3.65
34.45
4.25
36.87
4.48
39.28
4.82
44.11
5.47
48.93
6.16
6
24.80
3.17
29.62
3.72
34.45
4.33
36.87
4.58
39.28
4.92
44.11
5.58
48.93
6.30
8
24.80
3.23
29.62
3.78
34.45
4.41
36.87
4.67
39.28
5.02
44.11
5.69
48.93
6.40
10
24.80
3.29
29.62
3.86
34.45
4.48
36.87
4.80
39.28
5.12
44.11
5.79
48.93
6.50
12
24.80
3.35
29.62
3.93
34.45
4.56
36.87
4.88
39.28
5.20
44.11
5.90
48.93
6.60
14
24.80
3.40
29.62
3.99
34.45
4.63
36.87
4.97
39.28
5.31
44.11
6.01
48.93
6.73
16
24.80
3.44
29.62
4.05
34.45
4.71
36.87
5.05
39.28
5.39
44.11
6.11
48.93
6.86
18
24.80
3.50
29.62
4.12
34.45
4.80
36.87
5.14
39.28
5.50
44.11
6.22
48.93
6.98
20
24.80
3.54
29.62
4.20
34.45
4.88
36.87
5.24
39.28
5.60
44.11
6.35
48.93
7.13
21
24.80
3.59
29.62
4.22
34.45
4.93
36.87
5.29
39.28
5.65
44.11
6.41
48.93
7.20
23
24.80
3.63
29.62
4.31
34.45
5.01
36.87
5.39
39.28
5.75
44.11
6.67
48.93
7.66
25
24.80
3.69
29.62
4.37
34.45
5.20
36.87
5.65
39.28
6.11
44.11
7.11
48.93
8.17
27
24.80
3.84
29.62
4.65
34.45
5.54
36.87
6.03
39.28
6.52
44.11
7.58
48.93
8.72
29
24.80
4.05
29.62
4.93
34.45
5.90
36.87
6.41
39.28
6.94
44.11
8.09
48.93
9.32
31
24.80
4.31
29.62
5.22
34.45
6.26
36.87
6.81
39.28
7.39
44.11
8.60
48.93
9.91
33
24.80
4.54
29.62
5.54
34.45
6.64
36.87
7.24
39.28
7.85
44.11
9.15
48.93
10.57
35
24.80
4.82
29.62
5.88
34.45
7.05
36.87
7.68
39.28
8.34
44.11
9.74
48.93
11.25
37
24.80
5.09
29.62
6.22
34.45
7.47
36.87
8.15
39.28
8.85
44.11
10.36
48.93
11.97
39
24.80
5.37
29.62
6.58
34.45
7.92
36.87
8.64
39.28
9.40
44.11
11.00
48.93
12.74
41
24.80
5.54
29.62
6.86
34.45
8.21
36.87
8.99
39.28
9.75
44.11
11.51
48.93
13.31
43
24.63
5.68
29.43
7.11
34.23
8.44
36.62
9.19
39.02
10.02
43.82
11.92
48.61
13.80
46
24.63
5.95
29.43
7.47
34.23
8.78
36.62
9.54
39.02
10.52
43.82
12.46
48.61
14.56
48
24.63
6.17
29.43
7.79
34.23
9.08
36.62
9.77
39.02
10.92
43.82
12.90
48.61
15.27
50
24.46
6.19
29.08
7.82
33.91
9.14
36.33
9.84
38.53
10.98
43.36
12.99
48.20
15.33
52
23.99
6.22
28.57
7.86
33.44
9.17
35.60
9.87
38.02
11.04
42.63
13.02
47.46
15.39
55
23.73
6.27
28.35
7.91
32.92
9.23
35.12
9.92
37.54
11.09
42.15
13.11
46.73
15.50
25%
-5
12.39
1.55
14.82
1.79
17.18
2.05
18.36
2.15
19.54
2.27
21.90
2.58
24.39
2.78
-2
12.39
1.56
14.82
1.82
17.18
2.08
18.36
2.18
19.54
2.31
21.90
2.61
24.39
2.82
0
12.39
1.58
14.82
1.85
17.18
2.11
18.36
2.21
19.54
2.34
21.90
2.66
24.39
2.87
2
12.39
1.60
14.82
1.88
17.18
2.15
18.36
2.24
19.54
2.38
21.90
2.67
24.39
2.92
4
12.39
1.62
14.82
1.91
17.18
2.17
18.36
2.27
19.54
2.42
21.90
2.74
24.39
3.00
6
12.39
1.65
14.82
1.94
17.18
2.21
18.36
2.32
19.54
2.47
21.90
2.78
24.39
3.08
8
12.39
1.69
14.82
1.97
17.18
2.24
18.36
2.37
19.54
2.50
21.90
2.82
24.39
3.18
10
12.39
1.72
14.82
1.99
17.18
2.28
18.36
2.41
19.54
2.57
21.90
2.90
24.39
3.23
12
12.39
1.74
14.82
2.02
17.18
2.32
18.36
2.46
19.54
2.63
21.90
2.95
24.39
3.28
14
12.39
1.76
14.82
2.05
17.18
2.34
18.36
2.51
19.54
2.66
21.90
3.00
24.39
3.35
16
12.39
1.79
14.82
2.07
17.18
2.38
18.36
2.55
19.54
2.70
21.90
3.05
24.39
3.40
18
12.39
1.81
14.82
2.11
17.18
2.42
18.36
2.59
19.54
2.75
21.90
3.10
24.39
3.46
20
12.39
1.84
14.82
2.14
17.18
2.46
18.36
2.63
19.54
2.81
21.90
3.15
24.39
3.53
21
12.39
1.85
14.82
2.16
17.18
2.48
18.36
2.65
19.54
2.83
21.90
3.19
24.39
3.56
23
12.39
1.88
14.82
2.19
17.18
2.52
18.36
2.70
19.54
2.88
21.90
3.24
24.39
3.64
25
12.39
1.90
14.82
2.23
17.18
2.57
18.36
2.75
19.54
2.97
21.90
3.41
24.39
3.89
27
12.39
1.94
14.82
2.32
17.18
2.72
18.36
2.93
19.54
3.15
21.90
3.63
24.39
4.14
29
12.39
2.05
14.82
2.45
17.18
2.88
18.36
3.11
19.54
3.36
21.90
3.86
24.39
4.41
31
12.39
2.16
14.82
2.59
17.18
3.05
18.36
3.31
19.54
3.56
21.90
4.11
24.39
4.70
33
12.39
2.29
14.82
2.74
17.18
3.24
18.36
3.50
19.54
3.78
21.90
4.36
24.39
4.99
35
12.39
2.42
14.82
2.90
17.18
3.42
18.36
3.71
19.54
4.00
21.90
4.63
24.39
5.30
37
12.39
2.55
14.82
3.06
17.18
3.63
18.36
3.93
19.54
4.25
21.90
4.92
24.39
5.64
39
12.39
2.69
14.82
3.23
17.18
3.84
18.36
4.16
19.54
4.50
21.90
5.21
24.39
5.98
41
12.39
2.80
14.82
3.37
17.18
3.97
18.36
4.35
19.54
4.70
21.90
5.49
24.39
6.26
43
12.31
2.97
14.72
3.58
17.07
4.09
18.24
4.52
19.41
4.79
21.76
5.73
24.23
6.50
46
12.31
3.03
14.72
3.67
17.07
4.36
18.24
4.87
19.41
4.99
21.76
6.28
24.23
7.05
48
12.31
3.09
14.72
3.76
17.07
4.60
18.24
5.19
19.41
5.23
21.76
6.78
24.23
7.59
50
12.17
3.12
14.63
3.79
16.94
4.64
18.09
5.20
19.26
5.24
21.58
6.82
24.02
7.63
52
12.02
3.13
14.34
3.81
16.65
4.65
17.80
5.22
18.97
5.26
21.29
6.85
23.60
7.65
55
11.87
3.15
14.19
3.84
16.36
4.69
17.51
5.26
18.68
5.29
20.85
6.90
23.31
7.70
Abbreviations:
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
