Midea VC Pro Series Engineering Data Book
Table 2-8.23: 28HP cooling part load performance
Part
load
Outdoor
temperature (°C
DB)
Indoor temperature(°C DB/WB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
100%
-5
52.99
8.19
63.08
9.86
73.45
11.74
78.50
12.57
83.55
13.64
93.92
15.54
99.25
16.22
-2
52.99
8.29
63.08
9.99
73.45
11.87
78.50
12.81
83.55
13.82
93.92
15.73
99.25
16.33
0
52.99
8.37
63.08
10.09
73.45
12.00
78.50
12.96
83.55
13.95
93.92
15.99
99.25
16.51
2
52.99
8.54
63.08
10.23
73.45
12.13
78.50
13.13
83.55
14.11
93.92
16.22
99.25
16.77
4
52.99
8.60
63.08
10.33
73.45
12.31
78.50
13.33
83.55
14.29
93.92
16.38
99.25
16.95
6
52.99
8.72
63.08
10.54
73.45
12.47
78.50
13.56
83.55
14.50
93.92
16.61
99.25
17.21
8
52.99
8.89
63.08
10.69
73.45
12.70
78.50
13.72
83.55
14.74
93.92
16.87
99.25
17.50
10
52.99
9.00
63.08
10.90
73.45
12.90
78.50
13.95
83.55
15.01
93.92
17.15
99.25
17.75
12
52.99
9.14
63.08
11.11
73.45
13.14
78.50
14.20
83.55
15.29
93.92
17.47
97.84
17.89
14
52.99
9.31
63.08
11.32
73.45
13.39
78.50
14.48
83.55
15.57
93.92
17.82
96.72
18.10
16
52.99
9.49
63.08
11.53
73.45
13.67
78.50
14.76
83.55
15.89
93.36
18.03
95.32
18.31
18
52.99
9.67
63.08
11.74
73.45
13.92
78.50
15.04
83.55
16.20
92.24
18.63
94.20
18.77
20
52.99
9.84
63.08
11.99
73.45
14.34
78.50
15.81
83.55
17.36
90.83
19.51
92.79
19.68
21
52.99
9.95
63.08
12.09
73.45
14.87
78.50
16.38
83.55
17.96
90.28
19.96
92.24
20.14
23
52.99
10.19
63.08
12.90
73.45
15.92
78.50
17.54
83.55
19.26
89.15
20.88
90.83
21.05
25
52.99
10.86
63.08
13.78
73.45
17.05
78.50
18.80
83.55
20.63
87.76
21.79
89.71
21.97
27
52.99
11.60
63.08
14.69
73.45
18.21
78.50
20.11
83.55
22.07
86.35
22.71
88.31
22.92
29
52.99
12.34
63.08
15.68
73.45
19.44
78.50
21.48
83.26
23.44
85.23
23.65
87.19
23.83
31
52.99
13.14
63.08
16.73
73.45
20.74
78.50
22.92
82.14
24.36
83.83
24.57
85.78
24.78
33
52.99
13.95
63.08
17.82
73.45
22.11
78.50
24.46
80.75
25.27
82.71
25.48
84.67
25.73
35
52.99
14.83
63.08
18.94
73.45
23.58
78.50
26.08
79.34
26.18
81.30
26.43
83.26
26.64
37
52.99
15.78
63.08
20.18
73.45
25.13
77.09
26.99
78.22
27.13
80.18
27.38
81.87
27.59
39
52.99
16.76
63.08
21.44
73.45
26.75
75.97
27.91
76.81
28.05
78.78
28.29
80.75
28.58
41
52.99
17.55
63.08
22.22
73.45
27.73
74.79
28.10
76.22
28.48
77.41
28.96
79.57
29.16
43
52.06
18.00
61.98
22.59
72.17
27.73
72.33
27.92
74.35
28.23
76.51
28.62
76.80
28.95
46
52.06
19.02
61.98
23.61
72.17
28.20
70.79
28.30
73.97
28.75
75.87
29.06
75.26
29.34
48
52.06
19.86
61.98
24.44
72.17
28.25
67.88
28.62
73.85
29.26
71.24
29.36
73.61
29.61
50
51.45
19.97
61.24
24.56
71.35
28.37
67.34
28.76
73.12
29.37
70.42
29.53
72.81
29.76
52
50.83
20.03
60.32
24.66
70.42
28.48
66.10
28.86
71.96
29.53
69.50
29.63
71.96
29.86
55
49.90
20.15
59.39
24.84
69.19
28.71
65.18
29.09
71.04
29.71
68.26
29.81
70.73
30.09
75%
-5
39.81
5.58
47.65
6.55
55.19
7.42
59.11
7.95
63.03
8.49
70.57
9.71
78.41
11.16
-2
39.81
5.63
47.65
6.58
55.19
7.46
59.11
8.11
63.03
8.64
70.57
9.86
78.41
11.32
0
39.81
5.66
47.65
6.67
55.19
7.62
59.11
8.26
63.03
8.79
70.57
10.06
78.41
11.47
2
39.81
5.69
47.65
6.70
55.19
7.74
59.11
8.41
63.03
8.95
70.57
10.28
78.41
11.65
4
39.81
5.77
47.65
6.87
55.19
7.91
59.11
8.56
63.03
9.15
70.57
10.45
78.41
11.93
6
39.81
5.86
47.65
6.99
55.19
8.11
59.11
8.84
63.03
9.36
70.57
10.63
78.41
12.16
8
39.81
5.96
47.65
7.19
55.19
8.29
59.11
8.98
63.03
9.56
70.57
10.93
78.41
12.39
10
39.81
6.09
47.65
7.30
55.19
8.51
59.11
9.16
63.03
9.82
70.57
11.16
78.41
12.54
12
39.81
6.24
47.65
7.41
55.19
8.68
59.11
9.34
63.03
9.99
70.57
11.37
78.41
12.78
14
39.81
6.34
47.65
7.54
55.19
8.82
59.11
9.47
63.03
10.16
70.57
11.57
78.41
13.02
16
39.81
6.44
47.65
7.68
55.19
8.99
59.11
9.68
63.03
10.37
70.57
11.78
78.41
13.26
18
39.81
6.54
47.65
7.82
55.19
9.16
59.11
9.85
63.03
10.54
70.57
12.02
78.41
13.54
20
39.81
6.65
47.65
7.96
55.19
9.34
59.11
10.02
63.03
10.75
70.57
12.26
78.41
13.92
21
39.81
6.72
47.65
8.03
55.19
9.40
59.11
10.13
63.03
10.85
70.57
12.43
78.41
14.40
23
39.81
6.82
47.65
8.16
55.19
9.61
59.11
10.47
63.03
11.40
70.57
13.33
78.41
15.43
25
39.81
6.96
47.65
8.51
55.19
10.23
59.11
11.19
63.03
12.16
70.57
14.26
78.41
16.50
27
39.81
7.37
47.65
9.06
55.19
10.92
59.11
11.92
63.03
12.99
70.57
15.22
78.41
17.64
29
39.81
7.82
47.65
9.61
55.19
11.61
59.11
12.71
63.03
13.81
70.57
16.22
78.41
18.84
31
39.81
8.27
47.65
10.20
55.19
12.37
59.11
13.50
63.03
14.71
70.57
17.29
78.41
20.08
33
39.81
8.78
47.65
10.85
55.19
13.16
59.11
14.36
63.03
15.67
70.57
18.43
78.41
21.42
35
39.81
9.30
47.65
11.51
55.19
13.95
59.11
15.29
63.03
16.67
70.57
19.63
78.41
22.84
37
39.81
9.82
47.65
12.19
55.19
14.85
59.11
16.22
63.03
17.74
70.57
20.91
78.41
24.32
39
39.81
10.40
47.65
12.92
55.19
15.74
59.11
17.26
63.03
18.84
70.57
22.22
78.41
25.90
41
39.81
10.86
47.65
13.38
55.19
16.20
59.11
17.83
63.03
19.41
70.57
23.13
78.41
27.05
43
39.12
11.53
46.82
14.03
54.23
16.56
58.08
18.45
61.93
19.63
69.34
23.54
77.04
27.39
46
39.12
11.79
46.82
14.33
54.23
16.91
58.08
18.75
61.93
20.60
69.34
24.82
77.04
28.44
48
39.12
12.01
46.82
14.42
54.23
17.12
58.08
19.07
61.93
21.17
69.34
25.98
77.04
29.13
50
38.86
12.18
46.41
14.57
53.67
17.18
57.62
19.15
61.22
21.25
68.48
26.08
76.38
29.27
52
38.22
12.22
45.77
14.61
53.03
17.22
56.63
19.24
60.23
21.35
67.49
26.17
75.10
29.36
55
37.52
12.27
44.78
14.70
52.04
17.37
55.64
19.34
59.24
21.49
66.50
26.35
74.11
29.58
Abbreviations:
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Table continued on next page …
