Midea N series User Manual

23
1.2
Receiving board
assembly
201325290014
1.3
Front panel
201125190044
1.4
Cover of Air-out
frame assembly
201125190039
1.5
Panel(Mid)
201125190042
2
Display box assembly
2033252A0019
2.1
display board
assembly
2013254A0011
2.2
control panel
201125190157
3
E-part box cover
201225590019
4
E-Part box assembly
203325190028
4.1
Capacitor clamp
201225590021
4.2
Compressor capacitor
202401090005
4.3
Main control board
201325190032
4.4
Installation board for
Main control board
201125190038
4.5
Base of control box
201225590020
4.6
Capacitor
202401100122
4.6
Capacitor
202401100019
4.7
Transformer
202300900193
5
Inside fan scroll
assembly
201125190148
5.11
Bottom holder 1 of
indoor Volute Shell
201125190055
5.12
Net cover for Air out
frame
201225190010
5.13
Cover of indoor
Volute Shell
201125190054
5.14
Cross flow fan
assembly
201100200113
5.15
Fan motor
202400400978
5.16
Bottom holder 2 of
indoor Volute Shell
201125190056
5.17
Bearing holder
202730100201
6
Pin assembly
201125190082
7
Chassis assembly
2011251A0104
7.11
Water wheel
201125190046
7.12
Holder for fan motor
201225190019
7.13
Motor
202400700021
7.14
Micro switch holder
201125190048
7.15
Micro switch
202301830111
7.16
Dobber case
201125190047
7.17
Dobber
202225190001
7.18
Universal wheel
202725000002
7.19
Chassis
201125190049
7.20
Power cord
2024022A0195
8
Outside fan scroll
assembly
201125190154
8.1
Outdoor volute shell
201125190151
