26
6.18
Louver motor
202400200039
6.19
Cross flow fan
assembly
201100200114
6.20
Fan motor
202400400978
7
indoor frame
assembly
201125290031
8
Rear panel
assembly
201125290032
9
Fixing joint for
water drain
201125490271
10
Drain stopper
202725490002
10
Drain stopper
202725490013
11
Air discharger
201125690024
13
Outdoor wind
discharging pipe
201125190159
14
Air Outlet
Tie-in(round)
201125190130
16
Window sealing
board I
201125090001
17
Window sealing
board II
201125090002
18
Outside fan
scroll assembly
201125190149
18.1
Fan motor
202400400969
18.2
Outdoor volute
shell
201125290024
18.3
Outdoor
centrifugal fan
201100100702
18.4
Outdoor volute
shell cover
201125290025
19
Evaporator
201525190035
20
Compressor
201402000490
21
Condenser
201525290060
