25
3.4
Window for
receiving remote
controller signal
201125590042
4
E-Part box
assembly
203325390081
4.1
Installation
board for Main
control board
201125190038
4.2
Main control
board
201325190034
4.3
Transformer
202300900193
4.4
Capacitor clamp
201225590021
4.5
Base of control
box
201225590020
4.6
Compressor
capacitor
202401000810
4.7
Capacitor,Fan
Motor
202401100122
4.7
Capacitor,Fan
Motor
202401100019
5
Chassis
assembly
2011251A0112
5.11
Micro switch
202301830111
5.12
Micro switch
holder
201125190071
5.13
Dobber case
201125190072
5.14
Dobber
202225190001
5.15
Chassis
201125190070
5.16
Universal wheel
202725000002
5.17
Power cord
assembly
2024022A0228
5.18
Motor
202400700021
5.19
Holder for fan
motor
201225190019
5.20
Spring
201225490030
5.21
Water wheel
201125290026
6
Inside fan scroll
assembly
201125190150
6.11
Horizontal
louver,up
201125290035
6.12
Horizontal
louver,down
201125290036
6.13
Louver holder
assembly
201125290016
6.14
Net cover for Air
out frame
201225290004
6.15
Bottom holder of
indoor Volute
Shell
201125290007
6.16
Bearing holder
202730100201
6.17
Indoor Volute
Shell
201125290008
