Midea SMK-D140HHN1-3

High Temperature Hydro Module
202003 71
Service
Manual
PRESET TEMP. TIME6
PRESET TEMP. time 6
00:00
00:00
23:50
1/10
h/min
Temper.6
PRESET TEMP. 6
45
25
80
1
°C
weather temp. set
Temperature setting curve
on/off: OFF = 0, ON = 1
0
0
1
1
/
shift value
Temperature setting curve
shift value
0
-5
5
1
°C
multiple set point 1
required temp.
Sets water temperature at
multiple set point 1
65
25
80
1
°C
multiple set point 2
required temp.
Sets water temperature at
multiple set point 2
35
25
80
1
°C
DISINFECT CURRENT
STATE
Disinfection on/off: OFF = 0,
ON = 1
0
0
1
1
/
DISINFECT OPERATE
DAY
Disinfection week
FRI
MON
SUN
1
/
DISINFECT START
Start time for disinfection
23:00
00:00
23:50
1/10
h/min
DHW PUMPTIMER1-16
Pipeline water return pump
timer on/off: OFF = 0, ON = 1
0
0
1
1
/
DHW PUMP START 1-
16
Pipeline water return pump
start time: 1-16
00:00
00:00
23:50
1/10
h/min
TIMER1-TIMER6
Timers 1-6 on/off: 0 = Off，1 =
On
0
0
1
1
/
TIMER1-TIMER6
START
Timers 1-6 start time
00:00
00:00
23:50
1/10
h/min
TIMER1-TIMER6 END
Timers 1-6 end time
00:00
00:00
23:50
1/10
h/min
TIMER MODE 1-6
Timer mode: 0 = HEAT, 3 =
DHW
0
0
3
1
/
TIMER TEMP. 1-6
Temperature setting timer
45
25
80
1
°C
CANCEL TIMER
Cancels all the defined timers
0
0
1
1
/
SILENT MODE
CURRENT STATE
Silent mode on/off: 0 = Off，1
= On
0
1
1
1
/
SILENT TIMER
Silent mode timer on/off: 0 =
Off，1 = On
1
0
1
1
/
SILENT MODE TIMER
START 1
Silent mode timer start time 1
12:00
00:00
23:50
1/10
h/min
SILENT MODE TIMER
END 1
Silent mode timer end time 1
15:00
00:00
23:50
1/10
h/min
SILENT MODE TIMER
START 2
Silent mode timer start time 2
22:00
00:00
23:50
1/10
h/min
SILENT MODE TIMER
ENDT 2
Silent mode timer end time 2
07:00
00:00
23:50
1/10
h/min
HOLIDAY AWAY
CURRENT STATE
Holiday away mode on/off: 0 =
Off，1 = On
0
0
1
1
/
