Indoor unit installation
Installation 134
3.3 Ceiling & floor indoor unit installation
3.3.1 Service space for indoor unit
3.3.2 Bolt pitch
① Ceiling installation
Capacity (KBtu/h)
D
E
18/24
983
220
30K
1200
220
36~60
1565
220
② Wall-mounted installation
3.3.3 Install the pendant bolt
① Ceiling installation
