7 Installation detail
7.1 Position requirement for installation
Installation must be in a flat and spacious location where the air outlets will not be covered up. A
minimum clearance of 30cm from a wall or other obstacles should be kept. The appliance shall
not be used in the washroom. The plug shall accessible after appliance is positioned. Wiring shall
be done according to National rules. Please see the picture show as below.
7.2 Preparation work
First of all, prepare the exhaust hose as the below picture show to you.
Second, connect the exhaust hose with unit, like the blow picture.
After this two steps, please make sure the exhaust hose’s connect is OK.
Flat mouth
Use the screws to
install the flat mouth
