V6R VRF 50/60Hz
185
Part 3
-
System Design and Installation
V6R Series System Commissioning Report – Sheet G
Observed values
No.
Parameters displayed on DSP1
Remarks
Cooling
mode
Heating
mode
1
Operation IDU quantity
Actual value
2
System operation mode
0-OFF; 2-Cooling Only; 3-Heating Only; 5-Main Cooling
Mode; 6-Main Heating Mode
3
High pressure (MPa)
Actual value = value displayed × 0.1
4
Low pressure (MPa)
Actual value = value displayed × 0.01
5
Subcooler outlet temperature
Actual value = value displayed
6
Subcooler inlet temperature
Actual value = value displayed
7
EEV position
Actual value = value displayed × 10
8
Software version
9
MS Address
Actual value = value displayed
10
EBVA position
1
Actual value = value displayed × 10
11
EBVB position
1
Actual value = value displayed × 10
12
EBVC position
1
Actual value = value displayed × 10
13
Port No. for refrigerant leakage alarm
1
Actual value = value displayed
If there are multiple alarms at the same time, only the
minimum port number is displayed
14
Number of ports for refrigerant leakage alarm
1
Actual value = value displayed
15
Min (T2, T2B) of cooling operation IDU under the MS
1
Actual value = value displayed
If there is no cooling operation of the indoor unit, the
digital display "-"
Notes:
1. Number 10 to 15 are only for MS01.
Project name and location
System name
