Midea V6R Series

V6R VRF 50/60Hz
35
Part 2
-
Outdoor Unit Engineering Data
32/34/36/38/40HP
Figure 2-2.5: 32/34/36/28/40HP dimensions (unit: mm)
42/44HP
Figure 2-2.6: 42/44HP dimensions (unit: mm)
Outdoor unit 2
1635
1340
825
Outdoor unit 1
1635
1340
825
100-500
1635
790
990
100-500
Outdoor unit 2
Outdoor unit 3
1635
1340
825
Outdoor unit 1
1635
1340
825
100-500
