Center hinge
2.3 Reversing the Door Swing
Reversing the door position
Parts included with the hinge kit:
Parts already mounted on the door (as shipped):
Center left hinge
Screws (4)
Left top hinge cover
Top left hinge
Handle assembly
Plug (4)
Allen wrench Upper door
self-locking block
Left door-open
stopper
Center right hinge
Right top hinge cover
Top right hinge
Door block
Upper door
self-locking block
Right door-open
stopper
Bottom hinge
1 Unplug your refrigerator and remove all food from the door shelves.
2 Remove the left cover plate and the right top hinge cover, then
unscrew and remove the right top hinge. Keep the screws to reuse.
3 Lift the freezer door up and away from your refrigerator.
Right top
hinge cover
Left cover plate
4 Unscrew the three screws holding the center hinge, remove the hinge,
then lift the refrigerator door up and away from your refrigerator. Save
the screws to reuse.
To Next Page
