Midea Wine Cooler Series

Service Manual_2018-V2.0
17
7.Refrigerating piping system and circulating route of cooling air
7.1 Refrigerating piping system
Compressor→Whole condeser→Back condenser Dry filter tube→Capillary
tube→Evaporator→Suction tube→Compressor
7.2 Special soldering position(NONE)
