Service Manual_2018-V1.0
6
2.2 Water dispenser working principle
Principle of water diversion:
Generally, use bottled drinking water of 3 gallons and 5 gallons, insert the bucket into the bottle
supporter at the top of water dispenser reversely, the smart head in the
smart seat jacks up the seal cover in water bottle, so that water in bottle
enters into water dispenser through the inhalant orifice of smart seat, water
is stored in the water diversion chamber (or cold liner).
While, air also enters into the bucket through the hole in the bottle
supporter, by utilizing the balance of air pressure, the water level in
diversion chamber will remained at the mouth of the bucket eventually; by
utilizing the pressure difference of water level, the water in the diversion
chamber enters cold and hot water tanks for refrigeration and heating, user
controls water to discharge from faucet or drain outlet.
Cooling system (Compressor cooling):
:
Using semiconductor materials Peltier effect（ The role of electricity to
make the semiconductor cooling chip difference temperature ）， and then
through the heat exchange to achieve the cooling effect;
:
This cooling method: High thermal efficiency ，Low water temperature（＜10℃），Fast cooling，
and can option the refrigerator function
