0x11/ 17| 0 - 127 | 64 | LFO Amplitude
| | | 0x00..0x3f: negative range
| | | 0x40: no amplitude
| | | 0x41..0x7f: positive range
| | | Note: range is 0x00..0xff if edited from CS
--------+-----------+---------+---------------------------------------------
---
0x12/ 18| 0 - 99 | 0 | LFO Phase:
| | | 0: 0%
| | | 1: 1%
| | | 2: 2%
| | | ...
| | | 99: 99%
--------+-----------+---------+---------------------------------------------
---
0x13/ 19| 0 - 127 | 15 | LFO Interval in Steps:
| | | 0: 1 Step
| | | 1: 2 Steps
| | | 2: 3 Steps
| | | ...
| | | 127: 128 Steps
| | | Note: range is 1..256 steps if edited from
CS
--------+-----------+---------+---------------------------------------------
---
0x14/ 20| 0 - 127 | 15 | LFO Interval Reset:
| | | 0: after 1 Step
| | | 1: after 2 Steps
| | | 2: after 3 Steps
| | | ...
| | | 127: after 128 Steps
| | | Note: range is 1..256 steps if edited from
CS
--------+-----------+---------+---------------------------------------------
---
0x15/ 21| 0 - 31 | 0 | LFO Flags:
| | | bit 0: Oneshot Mode on/off
| | | bit 1: Note Assignment on/off
| | | bit 2: Velocity Assignment on/off
| | | bit 3: Length Assignment on/off
| | | bit 4: CC Assignment on/off
| | | bit 5: Extra CC Assignment off/on
(inverted!)
--------+-----------+---------+---------------------------------------------
---
0x16/ 22| 0 - 127 | 0 | LFO Extra CC Number
