MIDIPLUS Co, Ltd.
4
http://www.midiplus.com.tw
1.2.2. Rear Panel
TOM 4
CRASH 2
AUX IN
Left sound channel output/MONO
Right sound channel output
DB25 ： KICK 、 SNARE 、
TOM1~3、CRASH、RIDE、
HI-HAT、HH-CTRL
MIDI IN
MIDI OUT
DC 9V
POWER ON/OFF
HEADPHONE
USB
