Midland LXT110 Alignment Procedure

LXT110
PRODUCTION SPECIFICATION
Page 2
2. DETAILED SPECIFICATION
A. RECEIVER SECTIONS * Normal test condition *
TYP. LIMIT
1. MAXIMUM USABLE SENSITIVITY
* 1KHz +/-1.5KHz DEV.
* REF. CHANNEL 1 & 8
-122dBm <-119dBm
2. 20dB QUIETING SENSITIVITY
* 1HKz +/-1.5KHz DEV.
* REF. CHANNEL 1 & 8, 12dB SINADDER
-116dBm <-114dBm
3. ADJACENT CHANNEL TWO SIGNAL
SELECTIVITY & SENSITIZATION
* +/- 1 CHANNEL SPACING
>50dB
4. INTER-MODULATION SPURIOUS RESPONSE
ATTENUATION >50dB
5. SPURIOUS EMISSIONS
* CONDUCTIVE CONNECTION <-53dBm
6. RECEIVE FREQUENCY RESPONSE
* REF. 1KHz +/-1.5KHz DEV.
300Hz
3KHz
-4.0dB
-17.0dB
+/-2.0dB
+/-3.0dB
7. AUDIO OUTPUT LEVEL
* REF. 1KHz +/-1.5KHz DEV.
* (No LOAD )
* Volume Max.
1.5V >1.4V
8. AUDIO OUTPUT DISTORTION
* REF. 1KHz +/-1.5KHz DEV.
* ( No LOAD )
3% <5%
9. MAX. S/N RATIO
* REF. 1KHz +/-1.5KHz DEV.
* ( No LOAD )
36 dB >30dB
10. RX VCO REF. VOLTAGE
* REF. CHANNEL 1
* REF. CHANNEL 8
1.0V
2.0V
+/-0.3V
+/-0.3V
11. SQUELCH THRESHOLD
* REF. 1KHz +/-1.5KHz DEV.*
9dBsinadder -3dB - +3dB
16. CURRENT CONSUMPTION
* Un-squelched Volume Max.
* Squelched
* Power Off
200mA
35mA
200uA
+/-40mA
<40mA
<300uA
