Midland M-Mini USB - Display Overview; Back Panel Connections

4 | M-Mini-USB Instruction Guide
Display
9. Selected channel
10. Received signal strength indicator and trasmission power signal
11. AM/FM mode
12. RX/TX: reception (RX) and trasmission (TX) indicator
13. SC: SCAN function activated
14. AQ: Digital squelch activated
15. R: RFGAIN activated
Back panel
16. Power supply cable
17. External speacker
18. Antenna connector
ANT
EXT SP
DOWN UP
A/F SQ RFG EMG
910
12
13
14
15
11
ANT
EXT SP
DOWN UP
A/F SQ RFG EMG
16
1718
