6 | XT10 instruction guide
1. VOX function activated
2. Appears when the keypad lock is activated
3. Battery level
4. It is displayed when the radio is receiving a signal
5. Appears when the radio is transmitting (PTT pressed)
6. Indicates the selected CTCSS tone
7. Indicates the selected channel
8. Antenna
9. LCD Display
10. MON/SCAN. With this button you can enable/disable the Scan and
Monitor functions
11. MENU/ : Press this control to turn on/o the unit and to enter the ra-
dio’s menu.
12. ▲/▼: use these buttons to adjust the volume, select the channels and
functions
13. Microphone
14. Speaker
15. /CALL. Press this button to lock the keypad and to send out a call signal.
16. PTT button
17. Battery and battery compartment. The transceiver accepts 3 x AAA
alkaline/rechargeable batteries. To open the battery compartment, hold
the unit face down and slide the cover.
